Parameter 3-16 Reference Resource 2
Table 200: Parameter 3-16 Reference Resource 2
3-16 Reference Resource 2
Default value: [20] Digital pot.meter
Change during operation: True
Select the reference input to be used for the 2
nd
reference signal. Parameter 3-15 Resource Reference 1, parameter 3-16 Resource Refer-
ence 2, and parameter 3-17 Resource Reference 3 define up to 3 different reference signals. The sum of these reference signals defines
the actual reference. When parameter 1-00 Configuration Mode is set to [9] Positioning. Configure parameter 3-16 Reference Resource 2
to select the source for target position.
N O T I C E
The options [3],[4],[5], [6], [12], [13], and [14] are only available with software version 48.XX.
Single signal generated from 24 V High Threshold Logic (HTL) encoder connected to terminals
32 and 33. Configure the 24 V encoder interface in parameter group 5–7* 24 V Encoder Option.
Program terminals 32/33 to [0] No operation.
This is only available for VLT® Encoder Option MCB 102. Configure the encoder interface in pa-
rameter groups 17-0*, 17-1*, and 17-2*.
This is only available for VLT® Resolver Option MCB 103. Configure the resolver interface in pa-
rameter group 17-5* Resolver Interface.
Master signal for the drive which hosts the virtual master without an external connection. This
option is only active when option [10] Synchronization is selected in parameter 1-00 Configura-
tion Mode.
N O T I C E
This option is only available in FC 302.
Reference from terminals 68 and 69.
