Par . 3 − 52 = 
tdec s  × ns RPM
ref RPM
Parameter 3-55 Ramp 2 S-ramp Ratio at Accel. Start
Table 232: Parameter 3-55 Ramp 2 S-ramp Ratio at Accel. Start
3-55 Ramp 2 S-ramp Ratio at Accel. Start
Default value: 50%
Parameter type: Range, 1 - 99%
Setup: All setups
Conversion index: 0
Data type: Uint8
Change during operation: True
Enter the proportion of the total ramp-up time (parameter 3-51 Ramp 2 Ramp Up Time) in which the acceleration torque increases.
The larger the percentage value, the greater the jerk compensation achieved, and thus the lower the torque jerks occurring in the
application.
Parameter 3-56 Ramp 2 S-ramp Ratio at Accel. End
Table 233: Parameter 3-56 Ramp 2 S-ramp Ratio at Accel. End
3-56 Ramp 2 S-ramp Ratio at Accel. End
Default value: 50%
Parameter type: Range, 1 - 99%
Setup: All setups
Conversion index: 0
Data type: Uint8
Change during operation: True
Enter the proportion of the total ramp-up time (parameter 3-51 Ramp 2 Ramp Up Time) in which the acceleration torque decreases.
The larger the percentage value, the greater the jerk compensation achieved, and thus the lower the torque jerks in the application.
Parameter 3-57 Ramp 2 S-ramp Ratio Decel. Start
Table 234: Parameter 3-57 Ramp 2 S-ramp Ratio at Decel. Start
3-57 Ramp 2 S-ramp Ratio at Decel. Start
Default value: 50%
Parameter type: Range, 1 - 99%
Setup: All setups
Conversion index: 0
Data type: Uint8
Change during operation: True
Enter the proportion of the total ramp-down time (parameter 3-52 Ramp 1 Ramp Down Time) where the deceleration torque increa-
ses. The larger the percentage value, the greater the jerk compensation achieved, and thus the lower the torque jerks in the applica-
tion.
Parameter 3-58 Ramp 2 S-ramp Ratio at Decel. End
Table 235: Parameter 3-58 Ramp 2 S-ramp Ratio at Decel. End
3-58 Ramp 2 S-ramp Ratio at Decel. End
Default value: 50%
Parameter type: Range, 1 - 99%
Setup: All setups
Conversion index: 0
Data type: Uint8
Change during operation: True
Enter the proportion of the total ramp-down time (parameter 3-52 Ramp 2 Ramp Down Time) where the deceleration torque decrea-
ses. The larger the percentage value, the greater the jerk compensation achieved, and thus the lower the torque jerks in the applica-
tion.
5.4.7 3-6* Ramp 3
Parameter 3-60 Ramp 3 Type
Table 236: Parameter 3-60 Ramp 3 Type
3-60 Ramp 3 Type
Default value: [1] Linear
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
AU275636650261en-000101 / 130R0334146 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
