Option
Name
Description
Via the fieldbus.
Via [Reset].
Via a digital input.
[6]
Qstop and trip
N O T I C E
This option is only available with software version 48.XX.
Stops the motor with the quick stop ramp (parameter 3-81 Quick Stop Ramp Time). Perform a reset to
restart the drive.
[7]
Select setup 1
Changes the setup after a control word timeout. If communication resumes after a timeout, parameter
8-05 End-of-Timeout Function either resumes the setup used before the timeout, or retains the setup
endorsed by the timeout function.
[8]
Select setup 2
See [7] Select set-up 1.
[9]
Select setup 3
See [7] Select set-up 1.
[10]
Select setup 4
See [7] Select set-up 1.
[26]
Trip
Parameter 8-05 End-of-Timeout Function
Table 499: Parameter 8-05 End-of-Timeout Function
8-05 End-of-Timeout Function
Default value: [1] Resume set-up
Parameter type: Option
Setup: 1 setup
Conversion index: –
Data type: Uint8
Change during operation: True
Select the action after receiving a valid control word following a timeout. This parameter is active only when parameter 8-04 Control
Word Timeout Function is set to:
[7] Setup 1
[8] Setup 2
[9] Setup 3
[10] Setup 4
Option
Name
Description
[0]
Hold set-up
Retains the setup selected in parameter 8-04 Control Word Timeout Function and shows a warning until
parameter 8-06 Reset Control Word Timeout toggles. Then the drive resumes its original setup.
[1]*
Resume setup
Resumes the setup that was active before the timeout.
Parameter 8-06 Reset Control Word Timeout
Table 500: Parameter 8-06 Reset Control Word Timeout
8-06 Reset Control Word Timeout
Default value: [0] Do not reset
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
This parameter is active only when [0] Hold set-up has been selected in parameter 8-05 End-of-Timeout Function.
AU275636650261en-000101 / 130R0334 | 273Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
