Danfoss D9h Programming Guide

Option
Name
Description
[11]
Start homing
N O T I C E
This option is only available with software version 48.XX.
Starts the homing function selected in parameter 17-80 Homing Function. Must remain high until
homing is done, otherwise homing is aborted.
[12]
Activate touch
N O T I C E
This option is only available with software version 48.XX.
Activates monitoring of the touch sensor input.
[13]
Sync. to pos
mode
N O T I C E
This option is only available with software version 48.XX.
Select positioning in synchronization mode.
[14]
Ramp 2
N O T I C E
This option is only available with software version 48.XX.
Select between ramp 1 (parameter group 3-4* Ramp 1) and ramp 2 (parameter group 3-5* Ramp 2).
[15]
Relay 1
Control relay 1.
[16]
Relay 2
Control relay 1.
[17]
Speed mode
N O T I C E
This option is only available with software version 48.XX.
Select the speed mode when [9] Positioning or [10] Synchronization is selected in parameter 1-00
Configuration Mode. Speed reference is set by reference resource 1 or fieldbus REF1 relative to
parameter 3-03 Maximum Reference.
[18]
Enable vir. master
N O T I C E
This option is only available with software version 48.XX.
Enable the signal for the virtual master function. The option is applicable when [10] Synchroniza-
tion is selected in parameter 1-00 Configuration Mode.
[19]
Enable mast. off-
set
N O T I C E
This option is only available with software version 48.XX.
Activates the master offset selected in parameter 3-26 Master Offset when parameter 17-93 Master
Offset Selection has a selection from [1] Absolute to [5] Relative Touch Sensor.
[20]
Control word tog-
gle command
Changes the sign of the set target position. For example, if the set target is 1000, the activation of
this option changes the value to -1000.
AU275636650261en-000101 / 130R0334280 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
