Manufacturer-specific system ID.
Parameter 9-22 Telegram Selection
Table 548: Parameter 9-22 Telegram Selection
9-22 Telegram Selection
Default value: [100] None
Parameter type: Option
Setup: 1 setup
Conversion index: –
Data type: Uint8
Change during operation: True
Select a standard PROFIBUS telegram configuration for the drive as an alternative to the freely configurable telegrams in parameter
9-15 PCD Write Configuration and parameter 9-16 PCD Read Configuration.
Option
Name
Description
[1]
Standard telegram 1
[100]*
None
[101]
PPO 1
[102]
PPO 2
[103]
PPO 3
[104]
PPO 4
[105]
PPO 5
[106]
PPO 6
[107]
PPO 7
[108]
PPO 8
[200]
Custom telegram 1
[202]
Custom telegram 3
Parameter 9-23 Parameters for Signals
Table 549: Parameter 9-23 Parameters for Signals
9-23 Parameters for Signals
Default value: [0] None
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint16
Change during operation: True
This parameter contains a list of signals available for selection in parameter 9-15 PCD Write Configuration and parameter 9-16 PCD
Read Configuration.
Option
Name
Description
[0]*
None
[109]
Mode of operation
[302]
Minimum reference
[303]
Maximum reference
[312]
Catch up/slow down value
[321]
Touch target
AU275636650261en-000101 / 130R0334312 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
