Parameter 12-95 Inactivity Timeout
Table 665: Parameter 12-95 Inactivity Timeout
12-95 Inactivity Timeout
Default value: 120
Parameter type: Range, 0 - 3600
Setup: 2 setups
Conversion index: 0
Data type: Uint16
Change during operation: True
Applies to parameter 12-94 Broadcast Storm Protection, if the broadcast storm protection also includes multicast telegrams.
Parameter 12-96 Port Config
Table 666: Parameter 12-96 Port Config
12-96 Port Config
Default value: Size related
Parameter type: Option
Setup: 2 setups
Conversion index: –
Data type: Uint8
Change during operation: True
Enable or disable the port-mirroring function. The function is used for troubleshooting with a network analyzer tool.
Option
Name
Description
[0]
Normal
[1]
Mirror port 1 to 2
[2]
Mirror port 2 to 1
[10]
Port 1 disabled
[11]
Port 2 disabled
[254]
Mirror int. port to 1
[255]
Mirror int. port to 2
Parameter 12-97 QoS Priority
Table 667: Parameter 12-97 QoS Priority
12-97 QoS Priority
Default value: Size related
Parameter type: Range, 0 - 63
Setup: All setups
Conversion index: 0
Data type: Int8
Change during operation: True
Each index sets the DSCP value of different types of QoS prioritized messages.
Parameter 12-98 Interface Counters
Table 668: Parameter 12-98 Interface Counters
12-98 Interface Counters
Default value: 4000
Parameter type: Range, 0 - 4294967295
Setup: All setups
Conversion index: 0
Data type: Uint32
Change during operation: True
This parameter is read-only. Advanced interface counters from a built-in switch can be used for low-level troubleshooting. The pa-
rameter shows a sum of port 1 + port 2.
AU275636650261en-000101 / 130R0334 | 371Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
