Option
Name
Description
[26]
Logic rule 0
[27]
Logic rule 1
[28]
Logic rule 2
[29]
Logic rule 3
[33]
Digital input DI18
[34]
Digital input DI19
[35]
Digital input DI27
[36]
Digital input DI29
N O T I C E
This option is only available in FC 302.
[37]
Digital input DI32
[38]
Digital input DI33
[50]
Comparator 4
[51]
Comparator 5
[60]
Logic rule 4
[61]
Logic rule 5
Parameter 15-13 Logging Mode
Table 772: Parameter 15-13 Logging Mode
15-13 Logging Mode
Default value: [0] Log always
Parameter type: Option
Setup: 2 setups
Conversion index: -
Data type: Uint8
Change during operation: True
Option
Name
Description
[0]*
Log always
Select [0] Log always for continuous logging.
[1]
Log once on trigger
Select [1] Log once on trigger to start and stop logging conditionally using parameter 15-12 Trig-
ger Event and parameter 15-14 Samples Before Trigger.
Parameter 15-14 Samples Before Trigger
Table 773: Parameter 15-14 Samples Before Trigger
15-14 Samples Before Trigger
Default value: 50
Parameter type: Range, 0 - 100
Setup: 2 setups
Conversion index: 0
Data type: Uint8
Change during operation: True
Before a trigger event, enter the percentage of all samples which should be retained in the log. See also parameter 15-12 Trigger
Event and parameter 15-13 Logging Mode.
AU275636650261en-000101 / 130R0334 | 483Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
