DI T -33
DI T -32
DI T -29
DI T -27
DI T -19
DI T -18
DI T -37
DI X30/4
DI X30/3
DI X30/2
DI X46/13
DI X46/11
DI X46/9
DI X46/7
DI X46/5
DI X46/3
DI X46/1
e30ba894.11
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 00
Illustration 92: Relay Settings
Parameter 16-61 Terminal 53 Switch Setting
Table 875: Parameter 16-61 Terminal 53 Switch Setting
16-61 Terminal 53 Switch Setting
Default value: [0] Current
Parameter type: Option
Setup: All setups
Conversion index: -
Data type: Uint8
Change during operation: False
View the setting of input terminal 53.
Option
Name
Description
[0]*
Current
[1]
Voltage
Parameter 16-62 Analog Input 53
Table 876: Parameter 16-62 Analog Input 53
16-62 Analog Input 53
Default value: 0
Parameter type: Range, -20 - 20
Setup: All setups
Conversion index: -3
Data type: Int32
Change during operation: False
View the actual value at input 53.
Parameter 16-63 Terminal 54 Switch Setting
Table 877: Parameter 16-63 Terminal 54 Switch Setting
16-63 Terminal 54 Switch Setting
Default value: [0] Current
Parameter type: Option
Setup: All setups
Conversion index: -
Data type: Uint8
Change during operation: False
AU275636650261en-000101 / 130R0334508 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
