This parameter identifies which active inrush produces the data shown in parameter 18-70 Mains Voltage, parameter 18-71 Mains
Frequency, parameter 18-72 Mains Imbalance, and parameter 18-75 Rectifier DC Volt. 1 = inrush 1, 2 = inrush 2, and so on.
Parameter 18-74 Inrush Mode
Table 1007: Parameter 18-74 Inrush Mode
18-74 Inrush Mode
Default value: 0
Parameter type: Range, 0 - 1000, Array [4]
Setup: All setups
Conversion index: 0
Data type: Uint16
Change during operation: True
This parameter shows the reported mode of each inrush board. The values are:
0 = unknown
1 = inrush
2 = running
The indices are as follows:
0 = inrush1
1 = inrush2
2 = inrush3
3 = inrush4
Parameter 18-75 Rectifier DC Volt
Table 1008: Parameter 18-75 Rectifier DC Volt
18-75 Rectifier DC Volt
Default value: 0 V
Parameter type: Range, 0 - 10000 V
Setup: All setups
Conversion index: 0
Data type: Uint16
Change during operation: True
Shows the DC voltage measured on the rectifier module.
Parameter 18-76 Mains Voltage 2
Table 1009: Parameter 18-76 Mains Voltage 2
18-76 Mains Voltage 2
Default value: 0 V
Parameter type: Range, 0 - 1000 V, Array [16]
Setup: All setups
Conversion index: 0
Data type: Uint16
Change during operation: True
View the mains line-to-line measurements. The values are RMS. The indices are as follows:
0 = inrush1 average
1 = inrush2 average
4 = inrush1 L1
5 = inrush2 L1
8 = inrush1 L2
9 = inrush2 L2
= inrush1 L3
= inrush2 L3
AU275636650261en-000101 / 130R0334 | 547Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
