Option
Name
Description
[197]
RS Flipflop 5
[198]
RS Flipflop 6
[199]
RS Flipflop 7
[221]
IGBT-cooling
[222]
Homing OK
[223]
On target
[224]
Position limit
[225]
Position error
[226]
Touch on target
[227]
Touch activated
[231]
In power lim. mot.
[232]
In power lim. gen.
[233]
In power limit
[234]
PE power off
[246]
Emcy mode was act.
[247]
Emergency mode
[249]
Emcy m OPR unexpected
[250]
Emcy mode limits
[254]
Testing emcy mode
Parameter 36-52 Terminal X49/9 Min. Scale
Table 1338: Parameter 36-52 Terminal X49/9 Min. Scale
36-52 Terminal X49/9 Min. Scale
Default value: 0%
Parameter type: Range, 0 - 200%
Setup: All setups
Conversion index: 0
Data type: Int16
Change during operation: True
Match the minimum output of terminal X49/9 with a required value. The required value is defined as a percentage of the value
selected in parameter 36-50 Terminal X49/9 Analogue Output. To know more about how this parameter works, see parameter 6-52
Terminal 42 Output Max Scale. The following example describes how the drive uses this parameter. Example:
Parameter 36-04 Terminal X49/9 Mode = [0] Voltage 0–10 V.
Parameter 36-50 Terminal X49/9 Analogue Output = [100] Output frequency.
Parameter 4-19 Max Output Frequency = 200 Hz.
Application requirement: If the output frequency is lower than 20 Hz, the output of terminal X49/9 should be 0 V. To fulfil the exam-
ple requirement, enter 10% in parameter 36-52 Terminal X49/9 Min. Scale.
AU275636650261en-000101 / 130R0334654 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
