Parameter 1-10 Motor Construction
Table 69: Parameter 1-10 Motor Construction
1-10 Motor Construction
Default value: [0] Asynchron
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: False
Select the motor design type.
N O T I C E
FC 301 allows only selection of induction motors.
Option
Name
Description
[0]*
Asynchron
Use for ASM/IM motors.
[1]
PM, non sali-
ent SPM
N O T I C E
This option is only available in FC 302.
Use for SPM motors, surface-mounted magnet. PM motors are divided into 2 groups, with either sur-
face-mounted (SPM)/non-salient magnets or interior-mounted (IPM)/ salient magnets.
[2]
PM, salient
IPM
N O T I C E
This option is only available in FC 302.
Use for IPM motors, interior-mounted magnet. PM motors are divided into 2 groups, with either sur-
face-mounted (SPM)/non-salient magnets or interior-mounted (IPM)/ salient magnets.
[5]
SynRM
Use for SynRM, synchronous reluctance motors.
[6]
PMaSynRM
Use for PMaSynRM, Permanent Magnet assisted synchronous reluctance motors.
Parameter 1-11 Motor Model
Table 70: Parameter 1-11 Motor Model
1-11 Motor Model
Default value: Size related
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: False
Automatically sets the factory values for the selected motor. If the default value [1] Std. Asynchron is used, determine settings man-
ually according to the selection in parameter 1-10 Motor Construction.
N O T I C E
There are no models available for SynRM motors.
AU275636650261en-000101 / 130R0334 | 73Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
