N O T I C E
Setting this parameter sets the following parameters to their default settings:
Parameter 1-15 Low Speed Filter Time Const.
Parameter 1-16 High Speed Filter Time Const.
Parameter 1-17 Voltage Filter Time Const.
Parameter 1-24 motor Current
Parameter 1-30 Stator Resistance (Rs)
Parameter 1-31 Rotor Resistance (Rr)
Parameter 1-33 Stator Leakage Reactance (X1)
Parameter 1-34 Rotor Leakage Reactance (X2)
Parameter 1-35 Main Reactance (Xh)
Parameter 1-36 Iron Loss Resistance (Rfe)
Parameter 4-18 Current Limit
Parameter 14-31 Current Lim Ctrl, Integration Time
Parameter 14-43 Motor Cosphi
Parameter 16-36 Inv. Nom. Current
Parameter 16-37 Inv. Max. Current
Parameter 45-33 Alarm High
Parameter 45-62 Load Threshold
Select the motor frequency value from the motor nameplate data. If a value other than 50 Hz or 60 Hz is selected, adapt the load-
independent settings in parameter 1-50 Motor Magnetisation at Zero Speed to parameter 1-53 Model Shift Frequency. For 87 Hz opera-
tion with 230/400 V motors, set the nameplate data for 230 V/50 Hz. To run at 87 Hz, adapt parameter 4-13 Motor Speed High Limit
[RPM] and parameter 3-03 Maximum Reference.
Parameter 1-24 Motor Current
Table 80: Parameter 1-24 Motor Current
1-24 Motor Current
Default value: Size related
Parameter type: Range, 0.1 - 10000.00 A
Setup: All setups
Conversion index: -2
Data type: Uint32
Change during operation: False
N O T I C E
This parameter cannot be adjusted while the motor is running.
AU275636650261en-000101 / 130R0334 | 77Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
