Danfoss DSH Series Application Guidelines

GENERAL INFORMATIONSYSTEM DESIGNINTEGRATION INTO SYSTEMORDERING INFORMATION PRODUCT INFORMATION
Trio assemblies
H
L
H1
L1
H
H1
L
L1




Trio model Composition
L D H L1 H1
Outline drawing number
mm inch mm inch mm inch mm inch mm inch
DSH420 3 x DSH140
1131 44.53 513 20.2 569 22.4 515 min 20.28 min
230 9.06

8556195
1118 44.02 513 20.2 569 22.4 511 min 20.12 min

8556187
DSH483 3 x DSH161
1131 44.53 513 20.2 569 22.4 515 min 20.28 min

8556195
1118 44.02 513 20.2 569 22.4 511 min 20.12 min

8556187
DSH552 3 x DSH184
1139 44.84 518 20.39 584 22.99 515 min 20.28 min

8556194
1139 44.84 518 20.39 584 22.99 511 min 20.12 min

8556193
DSH720 3 x DSH240 1467 57.76 543 21.38 731 28.78
535 min 21.06 min 211 8.31

8556118
DSH885 3 x DSH295 1467 57.76 543 21.38 731 28.78 8556118
DSH1140 3 x DSH381 1467 57.76
545*
594**
21.46*
23.39**
803 31.61

8556120
DSH1245 2xDSH381 + DSH485 1520 59.84
573*
594**
22.56*
23.39**
803 31.61 8556172
DSH1350 DSH381 + 2Xdsh485 1520 59.84
573*
590**
22.56*
23.23**
803 31.61
680 min 26.77 min 244 9.61
8556173
DSH1455 3 x DSH485 1520 59.84
573*
590**
22.56*
23.23**
803 31.61 8556138
* compressor motor codes 4, 7, 9
** compressor motor code 3
Trio to be acheived by assembly of individual compressors
H
H1
D
L1
L
H
H1
L1
L
D
Dimensions
14 FRCC.PC.045.A7.02
