GENERAL INFORMATIONSYSTEM DESIGNINTEGRATION INTO SYSTEMORDERING INFORMATION PRODUCT INFORMATION
Technical specifications
50-60Hz data
Single compressor
Model
Nominal
tons 60Hz
Nominal cooling
capacity
Power
input
COP E.E.R. Swept volume
Displacement
Oil charge
Net weight
TR W Btu/h kW W/W Btu/h/W cm
3
/rev cu.in/rev m
3
/h cu.ft/h dm
3
oz kg lbs
50Hz
DSH090 7.5 20050 68413 6.54 3.06 10.46 88.4 5.39 15.4 544 3.0 102 58 128
DSH105 9.0 23580 80457 7.65 3.08 10.52 103.5 6.32 18.0 636 3.3 113 64 141
DSH120 10.0 26790 91410 8.61 3.11 10.62 116.9 7.13 20.3 717 3.3 113 64 141
DSH140 12.0 30370 103625 9.69 3.13 10.69 133 8.12 23.1 816 3.3 113 67 148
DSH161 13.0 34890 119 0 48 11.03 3.16 10.79 151.7 9.26 26.4 932 3.3 113 69 152
DSH184 15.0 39040 133208 12.36 3.16 10.78 170.3 10.39 29.6 1045 3.6 123 71.5 158
DSH240 20.0 52730 179920 17.04 3.09 10.56 227.60 13.89 39.6 1398 6.7 229 108 238
DSH295 25.0 64520 220149 20.35 3.17 10.82 276.20 16.85 48.1 1699 6.7 229 111 245
DSH381 30.0 81490 278052 26.21 3.11 10.61 345.00 21.05 60 2119 6.7 229 159 351
DSH485 40.0 103500 353152 32.72 3.16 10.79 442.60 27.01 77 2719 6.7 229 175 386
60Hz
DSH090 7.5 27470 93730 8.55 3.21 10.96 88.4 5.39 18.6 657 3.0 102 58 128
DSH105 9.0 32280 110100 10.01 3.22 11.00 103.5 6.32 21.8 770 3.3 113 64 141
DSH120 10.0 36630 125000 11.25 3.26 11.11 116.9 7.13 24.6 869 3.3 113 64 141
DSH140 12.0 41510 141600 12.75 3.26 11.11 133 8.12 27.9 985 3.3 113 67 148
DSH161 13.0 47220 16110 0 14.7 3.21 10.96 151.7 9.26 31.9 1127 3.3 113 69 152
DSH184 15.0 53160 181400 16.36 3.25 11.0 9 170.3 10.39 35.8 1264 3.6 123 71.5 158
DSH240 20.0 71760 244852 22.46 3.20 10.90 227.60 13.89 47.8 1688 6.7 229 108 238
DSH295 25.0 87610 298934 26.96 3.25 11.09 276.20 16.85 58 2048 6.7 229 111 245
DSH381 30.0 110300 376355 34.52 3.20 10.90 345.00 21.05 72.3 2553 6.7 229 159 351
DSH485 40.0 141900 484177 43.66 3.25 11.09 442.60 27.01 92.9 3281 6.7 229 175 386
Displacement at nominal speed: 2900rpm at 50Hz, 3500rpm at 60Hz
Net weight with oil charge
TR: Ton of Refrigeration, Standard rating conditions For 50Hz: Evaporating temperature: 5°C (41°F), Condensing temperature: 50°C (122°F), Superheat: 10K (18°F), Subcooling: 0K (0°F)
EER: Energy Efficiency Ratio Refrigerant: R410A For 60Hz: Evaporating temperature: 7.2°C (45°F), Condensing temperature: 54.4°C (130°F), Superheat: 11.1K (20°F), Subcooling: 8.3K (15°F)
COP: Coefficient Of Performance
Subject to modification without prior notification.
Data given for motor code 4 compressor with above condition, for full data details and capacity tables refer to Coolselector®2
www.coolselector.danfoss.com
7FRCC.PC.045.A7.02
