Danfoss DSH Series Application Guidelines

GENERAL INFORMATIONPRODUCT INFORMATIONINTEGRATION INTO SYSTEMORDERING INFORMATION SYSTEM DESIGN
Tandem and trio
requirements
Design piping
DSH tandem and trio use static oil balancing
principle to equalize oil level between the
compressors by gravity. This is ensured by a
precise suction and oil equalization piping
design.
The discharge line has no impact on oil
balancing. It is shown with tee, to indicate that
both left and right side discharge headers are
possible.
By default, DSH tandems and trios are not
factory-built.
To complete an assembly in the field, you will
need:
- Tubings, according to specific outline drawings
indicated in the following table.
- Manifolding accessory kit.
- Compressors.
For DSH240/295/381/485 you will need in
addition one mounting kit per compressor.
(7777045 for 50Hz application, 120Z0495 for
60Hz)
Suction and oil equalization piping
drawings must be respected (diameters,
minimum straight lengths, …)
R
Tandem model Composition Suction Discharge Oil equalization Kit tandem Code No
Outline drawing
number
DSH180E DSH090 + DSH090 1"5/8 1"3/8 1"1/8 120Z0634 8560115
DSH195U DSH090 + DSH105 1"5/8 1"3/8 1"1/8 120Z0694 8556233
DSH210U DSH090 + DSH120 1"5/8 1"3/8 1"1/8 120Z0694 8556233
DSH210E DSH105 + DSH105 1"5/8 1"3/8 1"1/8 120Z0634 8560114
DSH230U DSH090 + DSH140 1"5/8 1"3/8 1"1/8 120Z0694 8556233
DSH240E DSH120 + DSH120 1"5/8 1"3/8 1"1/8 120Z0634 8560114
DSH251U DSH090 + DSH161 1"5/8 1"3/8 1"1/8 120Z0694 8556233
DSH260U DSH140 + DSH120 1"5/8 1"3/8 1"1/8 120Z0692 8556230
DSH274U DSH090 + DSH184 1"5/8 1"3/8 1"1/8 120Z0693 8556232
DSH281U DSH161 + DSH120 1"5/8 1"3/8 1"1/8 120Z0692 8556230
DSH280E DSH140 + DSH140 1"5/8 1"3/8 1"1/8 120Z0634 8560114
DSH289U DSH105 + DSH184 1"5/8 1"3/8 1"1/8 120Z0693 8556231
DSH301U DSH161 + DSH140 1"5/8 1"3/8 1"1/8 120Z0692 8556230
DSH304U DSH120 + DSH184 1"5/8 1"3/8 1"1/8 120Z0694 8556231
DSH322E DSH161 + DSH161 1"5/8 1"3/8 1"1/8 120Z0634 8560114
DSH324U DSH140 + DSH184 1"5/8 1"3/8 1"1/8 120Z0694 8556231
DSH345U DSH161 + DSH184 1"5/8 1"3/8 1"1/8 120Z0694 8556231
DSH360X DSH120 + DSH240 2"1/8 1"3/8 1"3/8 120Z0709 8560128
DSH368E DSH184 + DSH184 1"5/8 1"3/8 1"1/8 120Z0634 8560113
DSH424X DSH184 + DSH240 2"1/8 1"3/8 1"3/8 120Z0709 8556259
DSH456X DSH161 + DSH295 2"1/8 1"3/8 1"3/8 120Z0709 8560128
DSH479X DSH184 + DSH295 2"1/8 1"3/8 1"3/8 120Z0709 8560259
DSH482 DSH240 + DSH240 2"1/8 1"5/8 1"3/8 7777041 8556112
DSH535 DSH240 + DSH295 2"1/8 1"5/8 1"3/8 7777037 8556112
DSH565X DSH184 + DSH381 2"1/8 1"3/8 1"3/8 120Z0709 8556260
DSH590 DSH295 + DSH295 2"1/8 1"5/8 1"3/8 7777041 8556112
DSH620 DSH240 + DSH381 2"1/8 1"5/8 1"3/8 7777048 8556115
DSH675 DSH295 + DSH381 2"1/8 1"5/8 1"3/8 7777037 8556115
DSH725 DSH240 + DSH485 2"1/8 1"5/8 1"5/8 120Z0569 8556134
DSH760 DSH381 + DSH381 2"1/8 1"5/8 1"3/8 7777041 8556117
DSH780 DSH295 + DSH485 2"5/8 1"5/8 1"5/8 120Z0551 8556141
DSH865 DSH381 + DSH485 2"5/8 1"5/8 1"5/8 120Z0550 8556136
DSH970 DSH485 + DSH485 2"5/8 1"5/8 1"5/8 120Z0578 8556137
Trio model Composition Suction Discharge Oil equalization Suction from
Kit tandem
Code No
Outline drawing
number
DSH420 3xDSH140 2"1/8 1"3/8 1"1/8
Left
120Z0672
8556195
Right 8556187
DSH483 3xDSH161 2"1/8 1"3/8 1"1/8
Left
120Z0684
8556195
Right 8556187
DSH552 3xDSH184 2"1/8 1"3/8 1"1/8
Left
120Z0685
8556194
Right 8556193
DSH720 3xDSH240 2"5/8 1"5/8 1"5/8
Left 120Z0673
8556118
Right 7777039
DSH885 3xDSH295 2"5/8 1"5/8 1"5/8
Left 120Z0673
8556118
Right 7777039
DSH1140 3xDSH381 2"5/8 1"5/8 1"5/8
Left 7777040
8556120
Right 7777049
DSH1245
2xDSH381 +
DSH485
2"5/8 2"1/8 1"5/8
Left
7777063 8556172
Right
DSH1350
DSH381 +
2xDSH485
3"1/8 2"1/8 1"5/8
Left
7777063 8556173
Right
DSH1455 3xDSH485 3"1/8 2"1/8 1"5/8
Left
7777040 8556138
Right
22 FRCC.PC.045.A7.02
