Design piping
Cp1 Cp2 Tandem Model Suction From Kit Code No To Order Washer Reference
Washer Inner
Diameter
Washer In Suction Of
DSH105 + DSH184 DSH289U
Left
120Z0693
5312497P03 23mm (0.91inch) Cp1
Right 5312497P03 23mm (0.91inch) Cp1
DSH140 + DSH161 DSH301U
Left
120Z0692
5312497P08 27.5mm (1.08inch) Cp1
Right 5312497P05 26mm (1.02inch) Cp1
DSH120 + DSH184 DSH304U
Left
120Z0694
5312497P06 24mm (0.94inch) Cp1
Right 5312497P06 24mm (0.94inch) Cp1
DSH161 + DSH161 DSH322E
Left
120Z0634 Not needed
Right
DSH140 + DSH184 DSH324U
Left
120Z0694
5312497P01 25mm (0.98inch) Cp1
Right 5312497P01 25mm (0.98inch) Cp1
DSH161 + DSH184 DSH345U
Left
120Z0694
5312639P08 27.5mm (1.08inch) Cp1
Right 5312639P08 27.5mm (1.08inch) Cp1
DSH120 + DSH240 DSH360X
Left
120Z0709
5312497P06 24mm (0.94inch) Cp1
Right 5312497P01 25mm (0.98inch) Cp1
DSH184 + DSH184 DSH368E
Left
120Z0634 Not needed
Right
DSH184 + DSH240 DSH424X
Left
120Z0709
5311579 P10 35.5mm (1.4inch) CP2
Right 5311579 P10 35.5mm (1.4inch) CP2
DSH161 + DSH295 DSH456X
Left
120Z0709
5312497P01 25mm (0.98inch) Cp1
Right 5312497P05 26mm (1.02inch) Cp1
DSH184 + DSH295 DSH479X
Left
120Z0709
5312497P05 26mm (1.02inch) CP1
Right 5312497P05 26mm (1.02inch) CP1
DSH240 + DSH240 DSH482
Left
7777041 Not needed
Right
DSH240 + DSH295 DSH535
Left
7777037 5311579P01 31mm (1.22inch) Cp1
Right
DSH184 + DSH381 DSH565X
Left
120Z0709
5312497P06 24mm (0.94inch) CP1
Right 5312497P06 24mm (0.94inch) CP1
DSH295 + DSH295 DSH590
Left
7777041 Not needed
Right
DSH240 + DSH381 DSH620
Left
7777048 5311579P05 29mm (1.14inch) Cp1
Right
DSH295 + DSH381 DSH675
Left
7777037 5311579 P01 31mm (1.22inch) Cp1
Right
DSH240 + DSH485 DSH725
Left
120Z0569 5311579P09 24mm (0.94inch) Cp1
Right
DSH381 + DSH381 DSH760
Left
7777041 Not needed
Right
DSH295 + DSH485 DSH780
Left
120Z0551 5311579 P07 27mm (1.06inch) Cp1
Right
DSH381 + DSH485 DSH865
Left
120Z0550 5311579P08 30mm (1.18inch) Cp1
Right
DSH485 + DSH485 DSH970
Left
120Z0578 Not needed
Right
Note:
For cross platform tandem application, which tandem model name ending with X, a external non-return valve (NRV) in highly recommended to install on
DSH120/161/184 discharge line.
