Danfoss DSH Series Application Guidelines

GENERAL INFORMATIONPRODUCT INFORMATIONSYSTEM DESIGNINTEGRATION INTO SYSTEMORDERING INFORMATION
Accessories
Acoustic hoods
Miscellaneous
Code no. Description Packaging Pack Size
8156019 Sight glass with gaskets (black & white) Multipack 4
8156129 Gasket for oil sight glass, 1"1/8 (white teflon) Multipack 10
7956005 Gasket for oil sight glass, 1"1/8 (white teflon) Multipack 50
8154001 Danfoss Commercial Compressors blue spray paint Single pack 1
Terminal boxes, covers and T-block connectors
Code no. Description Application Packaging Pack Size
120Z0413 Terminal box cover DSH184 - DSH140 code3 - DSH161 code3 Single pack 1
8156135
Service kit for terminal box 96 x 115 mm, including 1
cover, 1 clamp
DSH090 to 161 (except DSH140 code3 and
DSH161 code3)
Multipack 10
8173230 T block connector 52 x 57 mm
DSH090 to 161 (except DSH140 code3 and
DSH161 code3)
Multipack 10
8173021 T block connector 60 x 75 mm
DSH184 - DSH140 code3 - DSH161 code3
DSH240*-295*-381*
Multipack 10
8173331 T block connector 80x80 mm DSH240-295-381 code 3 DSH485 Multipack 10
120Z0458 Terminal box 210 x 190 mm, incl. cover DSH240-295-381*-485* Single pack 1
120Z0150 Terminal box cover DSH381 code 3 Single pack 1
120Z0604 Terminal box 210x340mm, incl. cover DSH485 code 3 Single pack 1
* except code 3
Code no. Description Application Packaging Pack Size
120Z0034 Acoustic hood for scroll compressor DSH090 Single pack 1
120Z0035 Acoustic hood for scroll compressor DSH105 to 161 (except DSH161-140 code3) Single pack 1
120Z0135 Acoustic hood for scroll compressor DSH184 - DSH140 code3 - DSH161 code3 Single pack 1
120Z0022 Acoustic hood for scroll compressor DSH240-295-381*-485* Single pack 1
120Z0579 Acoustic hood for scroll compressor DSH381 code 3 Single pack 1
120Z0353 Bottom insulation for scroll compressor DSH240-295-381-485 Single pack 1
* except code 3
Lubricant
Code no. Description Packaging Pack Size
7754023 POE lubricant, 1 litre can Single pack 1
120Z0571 POE lubricant, 2.5 litre can Single pack 1
63FRCC.PC.045.A7.02
