Danfoss EKE 1C User Manual

Figure 66: ON/OFF thermostat
T
S3
T
S4
R
Pe
T
S2
EEV
Danfoss 80G365.10
“Warm” brine / water
“Cooled” brine / water
Expansion valve
Plate heat exchanger

WARNING:
Need for Defrosting During cooling is not considered. If defrosting is needed another system must ensure defrosting
is done when needed.
Figure 67: ON/OFF thermostat
Off
Time
Temperature
Differential
Setpoint
Off OffOn On On
Cutin
Cutout
Time
thermostat
Danf
oss
80G300.10
Valve OD
Table 28: ON/OFF thermostat parameters
Parameter
Function
Description
R014
Thermostatic Mode (1-Cutin /cutout)
-Uses a temperature setpoint (parameter R101), and the
dierential con-
stant(R001).
-The temperature media is maintained at a level
dened by the set point.
-If the temperature is higher than the reference + the
dierential, the supper heat
control will start, and it stops when the temperature goes below the reference.
R015
Sensor
Select the used sensor S3 or S4
I041
S3 Temperature sensor
Only if S3 is selected in R015, Selection of the used Media temperature S3
I041
S4 Temperature sensor
Only if S4 is selected in R015, Selection of the used Media temperature S4
B101
Temperature setpoint, Deg C
Desired media temperature
R001
Dierential
Dierential
constant.
U118
Operational Status
7 = Thermo, cutout, (read value)
Superheat controller, Type EKE 1A, 1B, 1C, 1D
© Danfoss | Climate Solutions | 2022.06 BC398828796060en-000101 | 46
