8.1.7 Stop state alarm
Table 61: Stop state alarm
Trigger (how the alarm IS
raised)
Controller is in stop state
Controller not in stop state
The controller is standby due R012 Main
switch and/or DI main switch is o
8.1.8 Manual mode alarm
Table 62: Manual mode alarm
Trigger (how the alarm IS
raised)
Controller is in manual state
Controller not in manual state
The controller is manual control, no auto-
matic control is active, and many alarms
are disabled
8.2 Troubleshooting
Table 63: Troubleshooting
Regulation does not start on
using control modes i.e.,
MSS
DI is not connected, if dened as ON/OFF hardware switch.
Sensor / transmitter error.
Alarm conguration conict i.e. S2 sensor not dened or
no refrigerant selected.
Alarm: standby mode active i.e. Parameter R012 is OFF.
• Set R012 main switch to 1.
Pressure drops across evaporator too high.
• Check refrigerant ahead of expansion valve, If valve is
placed much higher than condenser outlet.
• Check pressure dierence.
Lack of sub cooling ahead of expansion valve.
• Limit max opening degree of the valve setting in con-
troller.
• Check refrigeration system capacity and compare with
expansion valve capacity.
• Use proper valve size, Suitable for the system.
Evaporator superheat too high.
• Check the section " High Superheat".
Pressure drop across the expansion valve less than valve is
sized for.
• Check pressure drop across expansion valve. Replace
with larger valve.
Expansion valve too small.
• Check refrigeration system capacity and compare with
expansion valve capacity. Replace with larger valve if
necessary.
• Check selected valve type in the controller valve list.
Expansion valve block with foreign material.
• Remove valve and examine the orice /piston.
Wrong selection of Refrigerant in the controller settings.
• Choose the correct Refrigerant from the pre-dened
list.
Lack of Charge in the system.
• Charge the system with appropriate refrigerant capaci-
ty.
• Check for leakage in the system.
Pressure transmitter ranges or type is wrongly dened.
• Dene the correct pressure range.
MOP set point is dened very low.
• Check the MOP setting, if Modbus is used, check if the
values have been scaled as indicated in the parameter
list
Evaporator wholly or partly iced up.
• Check ow as per design
chilled water temp too low
• Check temp set points as per Design
Low pressure cut out due to
compressor cut in and cut
out
• Check for digital input DI signal or its settings.
• Check section start- up problem and its solution.
