BC-HM VI.72.M4.02 Danfoss 11/97 3
Several EPU 2370 controls, side by side
Panel mounting
Wall mounting or on DIN rail
Removal from panel
When the control is mounted in a panel
cutout the easiest way to remove it is to
depress the retainer springs on the rear
and press it out of the cutout.
If there is no access to the rear of the
control, it can be tilted out of the cutout
by inserting a screwdriver in the two
recesses provided in both ends of the
unit.
