48 VI.72.M4.02 Danfoss 11/97 BC-HM
Row (–) Column 0-4 (+)
0-9
01234
0 P0.0 P0.1 P0.2 P0.3 P0.4
Status Software System Time switch Slave
generation number channel select adress
F: 6 F: 0,0 F: 15
1 P1.0 P1.1 P1.2 P1.3 P1.4
S1 actual S1 reference Total stop Balance Motor
brine brine F: 0 temperature constant
temperature temperature F: 17 °C F: 120 s
2 P2.0 P2.1 P2.4
S2 actual S2 reference X
p
- propor-
room room tional band
temperature temperature F: 50 K
3 P3.4
T
n
- integra-
tion time
F: 20 s
4 P4.4
N
z
-
neutral zone
F: 2 K
5 P5.0 P5.3 P5.4
S5 actual S5 scale mid- Tmax. flow
ext. setpoint point for ext. temperature
setpoint F: 50°C
F: 0 °C
6 P6.0 P6.2 P6.3 P6.4
S6 actual Compensation Compensation Tmin.- flow
compensation base point I factor I temperature
temperature F: 5 °C F: 0 times F: -20 °C
7 P7.0 P7.1 P7.2 P7.3 P7.4
S1 actual Alarm code Compensation Compensation K
p
- propor-
room/brine base point II factor II tional factor
temperature F: 25 °C F: 0 times F: 5 times
8 P8.0
Normal Settings in connection with sensor S2
temperature
F: 5 20 °C
9 P9.0 Settings in connection with sensors S4 and S6,
Reduced and ext. setpoint S5
temperature
F: 10 30 °C F: Factory setting
Factory settings - System types 6-A and 6-B
For further information see page 15 - 21.
