Danfoss ERC 211 User Guide

Function
Code
Min.
Max.
Unit
AP0
AP1
AP2
AP3
AP4
AP5
AP6
AP7
Fan during defrost
d09
OFF
on
on
on
OFF
OFF
OFF
OFF
OFF
-
Defrost stop sensor non=None (Time), Air = Sair
temp. sensor, dEF= S5 Defrost sensor
d10
non
dEF
non
non
(1)
non
(1)
non
(1)
dEF
(1)
dEF
(1)
non
-
Accumulated Compressor runtime to start defrost
(0=OFF)
d18
0
96
hour
0
0
0
0
0
0
-
-
Defrost on demand (20=OFF)
d19
0.0
20.0
K
20.0
20.0
(1)
20.0
(1)
20.0
(1)
20.0
20.0
-
-
Defrost delay after pull down cycle
d30
0
960
min
0
0
0
0
0
0
-
-
(1)
This option is a default setting in the controller and cannot be changed.
(1)
This option is a default setting in the controller and cannot be changed.
Fan control
Table 25: Fan control
Function
Code
Min.
Max.
Unit
AP0
AP1
AP2
AP3
AP4
AP5
AP6
AP7
Fan control
F--
Fan at compressor cutout (FAo=Fan always ON;
FFC=Fan follow compressor; FPL= Fan Pulsating)
F01
Fao
FPL
FAo
FAo
FAo
FAo
FAo
FAo
FAo
FAo
Fan stop evap. Temperature
F04
-50.0
50.0
°C
50.0
-
-
-
50.0
50.0
50.0
-
Fan ON Cycle
F07
0
180
min
2
2
2
2
2
2
(1)
2
2
Fan OFF cycle
F08
0
180
min
2
2
2
2
2
2
(1)
2
2
(1)
This option is a default setting in the controller and cannot be changed.
(1)
This option is a default setting in the controller and cannot be changed.
Compressor
Table 26: Compressor
Function
Code
Min.
Max.
Unit
AP0
AP1
AP2
AP3
AP4
AP5
AP6
AP7
Compressor
c--
Compressor / Heater minimum ON time
C01
0
30
min
0
0
0
0
0
0
0
0
Compressor /Heater minimum OFF time
C02
0
30
min
2
2
2
2
2
2
2
2
Compressor OFF delay at open door
C04
0
900
Sec
900
900
900
900
900
900
60
(1)
900
Zero crossing selection (YES / no)
C70
no
YES
YES
YES
YES
YES
YES
YES
YES
(1)
YES
(1)
This option is a default setting in the controller and cannot be changed.
(1)
This option is a default setting in the controller and cannot be changed.
Others
Table 27: Others
Function
Code
Min.
Max.
Unit
AP0
AP1
AP2
AP3
AP4
AP5
AP6
AP7
Others
o--
Delay of outputs at startup
o01
0
600
sec
10
10
10
10
10
10
10
(1)
10
DI1
conguration
nC= Not congured; Sdc = Status display output,
doo = Door alarm with resumption, doA = Door
alarm without resumption, SCH = Main switch, nig
= Day/ Night mode, rFd = Reference displasement,
EAL = External alarm, dEF = Defrost, Pud = Pull
down; Sc = Condensor Sensor
o02
nC
Sc
nC
nC
nC
nC
nC
nC
nC
nC
Serial address
o03
0
247
No
0
0
0
0
0
0
-
0
Password
o05
0
999
No
0
0
0
0
0
0
0
0
Sensor type (n5=NTC 5K, n10=NTC10K, ptc=PTC,
pt1=PT1000)
o06
(2)
n5
ptc
n10
n10
n10
n10
n10
n10
n10
n10
Cooling/Heating (rE=Cooling, Ht= Heating)
o07
(2)
rE
Ht
rE
rE
(1)
rE
(1)
rE
(1)
rE
(1)
rE
(1)
rE
Ht
(1)
Display Resolution
o15
0.1
1.0
0.1
0.1
0.1
0.1
0.1
0.1
0.1
(1)
0.1
DI2
conguration
nC= Not congured; Sdc = Status display output,
doo = Door alarm with resumption, doA = Door
alarm without resumption, SCH = Main switch, nig
= Day/Night mode, rFd = Reference displasement,
EAL = External alarm, dEF = Defrost, Pud = Pull
down
o37
nC
Pud
nC
nC
nC
nC
nC
nC
nC
nC
