Ordering
Table 40: ERC 21X controllers
Type
Description
Relay
Number
Code no.
ERC 211
ERC 211, Red LED, 115 V - Kit
1
1
080G3451
ERC 211, Red LED, 230 V - Kit
1
1
080G3453
ERC 211, Controller, Red LED, 230 V
1
1
080G3454
ERC 211, Controller, Red LED, 230 V, I-Pack
1
30
080G3459
ERC 213
ERC 213, Red LED, 230 V - Kit
3
1
080G3457
ERC 213, Controller, Red LED, 230 V
3
1
080G3458
ERC 213, Controller, Red LED, 230 V, I-Pack
3
30
080G3460
ERC 213 Red, 115 V USA - Kit
3
1
080G3467
ERC 213 Red, 230 V USA - Kit
3
1
080G3469
ERC 214
ERC 214, Controller, Red LED, 115 V, I-Pack
4
30
080G3466
ERC 214, Controller, Red LED, 230 V, I-Pack
4
30
080G3463
Table 41: Gateway and Programming Key
Type
Description
Number
Code no.
EKA 200
KoolKey - Gateway cum Programming key
1
080N0020
EKA 201
Mass Programming Key
1
080N0021
Sensors
Table 42: Sensors
Type
Sensor element
Sensor housing
Cable
Number
Code no.
EKS 211
NTC 5000 ohm / 25 °C (Beta =3980 at 25/100 °C)
Thermo plastic polyester 8x30
1.5 m
150
084B4403
Thermo plastic polyester 8x30
3.5 m
75
084B4404
Thermo plastic polyester 8x30
1.5 m
1
084N1220
Thermo plastic polyester 8x30
3.5 m
1
084N1221
EKS 221
NTC 10000 ohm / 25 °C (Beta =3435 at 25/85 °C)
Thermo plastic rubber 6x5x15
3.5 m
150
084N3206
Thermo plastic rubber 6x5x15
3.5 m
1
084N3210
Thermo plastic rubber 6x5x15
8.5 m
50
084N3208
Thermo plastic rubber 6x5x15
8.5 m
1
084N3209
Stainless steel 6x20
1.5 m
150
084N3200
EKS 111
PTC 990 ohm / 25 °C
Stainless steel 6x30
1.5 m
1
084N1178
Stainless steel 6x30
1.5 m
150
084N1161
Stainless steel 6x30
3.5 m
1
084N1179
Stainless steel 6x30
3.5 m
150
084N1163
Stainless steel 6x30
6 m
1
084N1180
Stainless steel 6x30
6 m
80
084N1173
Stainless steel 6x30
8.5 m
60
084N1168
AKS 11
PT1000
Top part: PPO (Noryl)
3.5 m
1
084N0003
Bottom: stainless steel
Top part: PPO (Noryl)
5.5 m
1
084N0005
Bottom: stainless steel
Top part: PPO (Noryl)
8.5 m
1
084N0008
Bottom: stainless steel
AKS 12
PT1000
Stainless steel 6x40
1.5 m
1
084N0036
Stainless steel 6x40
1.5 m
30
084N0035
Stainless steel 6x40
3.5 m
30
084N0039
Stainless steel 6x40
5.5 m
30
084N0038

NOTE:
All the mounted sensors must be of same type.
Electronic refrigeration control, type ERC 21X
© Danfoss | Climate Solutions | 2023.01 BC194286421698en-000901 | 34
