Recommended max. fuse
Power
[kW]
SIBA
Type RK1
Littel fuse
Type RK1
Ferraz-
Shawmut
Type CC
Ferraz-
Shawmut
Type RK1
Bussmann
JFHR2
Ferraz-
Shawmut J
Ferraz-
Shawmut
JFHR2
1)
Littel fuse
JFHR2
1.1-2.2 5017906-010 KLS-R-10 ATM-R-10 A6K-10-R FWH-10 HSJ-10 - -
3 5017906-016 KLS-R-15 ATM-R-15 A6K-15-R FWH-15 HSJ-15 - -
4 5017906-020 KLS-R-20 ATM-R-20 A6K-20-R FWH-20 HSJ-20 - -
5.5 5017906-025 KLS-R-25 ATM-R-25 A6K-25-R FWH-25 HSJ-25 - -
7.5 5012406-032 KLS-R-30 ATM-R-30 A6K-30-R FWH-30 HSJ-30 - -
11/15 5014006-040 KLS-R-40 - A6K-40-R FWH-40 HSJ-40 - -
18 5014006-050 KLS-R-50 - A6K-50-R FWH-50 HSJ-50 - -
22 5014006-063 KLS-R-60 - A6K-60-R FWH-60 HSJ-60 - -
30 2028220-100 KLS-R-80 - A6K-80-R FWH-80 HSJ-80 - -
37 2028220-125 KLS-R-100 - A6K-100-R FWH-100 HSJ-100 - -
45 2028220-125 KLS-R-125 - A6K-125-R FWH-125 HSJ-125 - -
55 2028220-160 KLS-R-150 - A6K-150-R FWH-150 HSJ-150 - -
75 2028220-200 KLS-R-200 - A6K-200-R FWH-200 HSJ-200 A50-P-225 L50-S-225
90 2028220-250 KLS-R-250 - A6K-250-R FWH-250 HSJ-250 A50-P-250 L50-S-250
Table 8.15 3x380-480 V, Enclosure Types A, B and C
1)
Ferraz-Shawmut A50QS fuses may substitute A50P fuses.
3x525-600 V
Recommended max. fuse
Power
[kW]
Buss-
mann
Type RK1
Buss-
mann
Type J
Buss-
mann
Type T
Buss-
mann
Type CC
Buss-
mann
Type CC
Buss-
mann
Type CC
SIBA
Type RK1
Littel fuse
Type RK1
Ferraz-
Shawmut
Type RK1
Ferraz-
Shawmut
J
1.1 KTS-R-5 JKS-5 JJS-6 FNQ-R-5 KTK-R-5 LP-CC-5 5017906-005 KLS-R-005 A6K-5-R HSJ-6
1.5-2.2 KTS-R-10 JKS-10 JJS-10 FNQ-R-10 KTK-R-10 LP-CC-10 5017906-010 KLS-R-010 A6K-10-R HSJ-10
3 KTS-R15 JKS-15 JJS-15 FNQ-R-15 KTK-R-15 LP-CC-15 5017906-016 KLS-R-015 A6K-15-R HSJ-15
4 KTS-R20 JKS-20 JJS-20 FNQ-R-20 KTK-R-20 LP-CC-20 5017906-020 KLS-R-020 A6K-20-R HSJ-20
5.5 KTS-R-25 JKS-25 JJS-25 FNQ-R-25 KTK-R-25 LP-CC-25 5017906-025 KLS-R-025 A6K-25-R HSJ-25
7.5 KTS-R-30 JKS-30 JJS-30 FNQ-R-30 KTK-R-30 LP-CC-30 5017906-030 KLS-R-030 A6K-30-R HSJ-30
11/15 KTS-R-35 JKS-35 JJS-35 - - - 5014006-040 KLS-R-035 A6K-35-R HSJ-35
18 KTS-R-45 JKS-45 JJS-45 - - - 5014006-050 KLS-R-045 A6K-45-R HSJ-45
22 KTS-R-50 JKS-50 JJS-50 - - - 5014006-050 KLS-R-050 A6K-50-R HSJ-50
30 KTS-R-60 JKS-60 JJS-60 - - - 5014006-063 KLS-R-060 A6K-60-R HSJ-60
37 KTS-R-80 JKS-80 JJS-80 - - - 5014006-080 KLS-R-075 A6K-80-R HSJ-80
45 KTS-R-100 JKS-100 JJS-100 - - - 5014006-100 KLS-R-100 A6K-100-R HSJ-100
55 KTS-R-125 JKS-125 JJS-125 - - - 2028220-125 KLS-R-125 A6K-125-R HSJ-125
75 KTS-R-150 JKS-150 JJS-150 - - - 2028220-150 KLS-R-150 A6K-150-R HSJ-150
90 KTS-R-175 JKS-175 JJS-175 - - - 2028220-200 KLS-R-175 A6K-175-R HSJ-175
Table 8.16 3x525-600 V, Enclosure Types A, B and C
