Enclosure Type [kW]
A2 A3 A4 A5 B1 B2 B3 B4 C1 C2 C3 C4
200–240 V 380–480 V 525–600 V
1.1–2.2 1.1–4.0
3.0–3.7 5.5–7.5 1.1–7.5
1.1–2.2 1.1–4.0
1.1–3.7 1.1–7.5 1.1–7.5
5.5–11
11–18.5 11–18.5
15
22–30 11–30
5.5–11
11–18.5 11–18.5
15–18.5
22–37 22–37
18.5–30
37–55 37–55
37–45 75–90 37–90
22–30 45–55 45–55
37–45 75–90 75–90
Screw holes (in [mm])
c 0.315
[8.0]
0.315
[8.0]
0.315
[8.0]
0.315
[8.0]
0.32 [8.2] 0.32 [8.2] 0.47 [12] 0.47 [12] 0.315 [8] - 0.47 [12] 0.47 [12] - -
Diameter Ø
d
0.43
[11]
0.43
[11]
0.43
[11]
0.43
[11]
0.47 [12] 0.47 [12] 0.75 [19] 0.75 [19] 0.47 [12] - 0.75 [19] 0.75 [19] - -
Diameter Ø
e
0.22
[5.5]
0.22
[5.5]
0.22
[5.5]
0.22
[5.5]
0.26 [6.5] 0.26 [6.5] 0.35 [9] 0.35 [9] 0.27 [6.8] 0.34 [8.5] 0.35 [9.0] 0.35 [9.0] 0.34 [8.5] 0.34 [8.5]
f 0.35 [9] 0.35 [9] 0.35 [9] 0.35 [9] 0.24 [6] 0.35 [9] 0.35 [9] 0.35 [9] 0.31 [7.9] 0.59 [15] 0.39 [9.8] 0.39 [9.8] 0.67 [17] 0.67 [17]
Max. weight (lbs [kg])
10.8
[4.9]
11.7
[5.3]
14.6
[6.6]
15.5
[7.0]
21.4 [9.7] 31 [14] 51 [23] 59.6 [27] 26.5 [12] 52 [23.5] 99.2 [45]
143.3
[65]
77.2 [35] 110.3 [50]
* See Figure 3.4 and Figure 3.5 for top and bottom mounting holes. ** Depth of enclosure will vary with different options installed.
Table 8.17 Power Ratings, Weight and Dimensions
