16-71 Relay Output [bin]
Range: Function:
0 N/A
*
[0 - 511 N/A] View the settings of all relays.
R eadout choic e (P ar . 16-71):
R ela y output (bin):
OptionB car d r ela y 08
OptionB car d r ela y 07
P o w er car d r ela y 02
P o w er car d r ela y 01
OptionB car d r ela y 09
130BA195.10
0 0 0
0 0 bin
16-72 Counter A
Range: Function:
0
*
[-2147483648 -
2147483647 ]
View the present value of Counter A.
Counters are useful as comparator
operands, see 13-10 Comparator Operand.
The value can be reset or changed either via
digital inputs (par. group 5-1*) or by using
an SLC action (13-52 SL Controller Action).
16-73 Counter B
Range: Function:
0
*
[-2147483648 -
2147483647 ]
View the present value of Counter B.
Counters are useful as comparator operands
(13-10 Comparator Operand).
The value can be reset or changed either via
digital inputs (par. group 5-1*) or by using
an SLC action (13-52 SL Controller Action).
16-74 Prec. Stop Counter
Range: Function:
0
*
[0 - 2147483647 ] Returns the actual counter value of precise
counter (1-84 Precise Stop Counter Value).
16-75 Analog In X30/11
Range: Function:
0.000 N/A
*
[-20.000 - 20.000 N/
A]
View the actual value at input
X30/11 of MCB 101.
16-76 Analog In X30/12
Range: Function:
0.000 N/A
*
[-20.000 - 20.000 N/
A]
View the actual value at input
X30/12 of MCB 101.
16-77 Analog Out X30/8 [mA]
Range: Function:
0.000 N/A
*
[0.000 - 30.000 N/A] View the actual value at input
X30/8 in mA.
16-78 Analog Out X45/1 [mA]
Range: Function:
0.000
*
[0.000 - 30.000 ] View the actual value at output X45/1.
The value shown reflects the selection
in 6-70 Terminal X45/1 Output.
16-79 Analog Out X45/3 [mA]
Range: Function:
0.000
*
[0.000 - 30.000 ] View the actual value at output X45/3.
The value shown reflects the selection
in 6-80 Terminal X45/3 Output.
3.17.6 16-8* Fieldbus & FC Port
Parameters for reporting the BUS references and control
words.
16-80 Fieldbus CTW 1
Range: Function:
0 N/A
*
[0 - 65535
N/A]
View the two-byte control word (CTW)
received from the bus master. Interpretation
of the control word depends on the serial
communication bus option installed and the
control word profile selected in 8-10 Control
Profile.
For more information, refer to the relevant
serial communication bus manual.
16-82 Fieldbus REF 1
Range: Function:
0 N/A
*
[-200 - 200
N/A]
View the two-byte word sent with the
control word form the bus master to set the
reference value.
For more information, refer to the relevant
serial communication bus manual.
16-84 Comm. Option Status
Range: Function:
0 N/A
*
[0 - 65535 N/
A]
View the extended serial communication
bus comm. option status word.
For more information, refer to the
relevant serial communication bus
manual.
