16-85 FC Port CTW 1
Range: Function:
0 N/A
*
[0 - 65535 N/
A]
View the two-byte control word (CTW)
received from the bus master. Interpre-
tation of the control word depends on the
serial communication bus option installed
and the control word profile selected in
8-10 Control Profile.
16-86 FC Port REF 1
Range: Function:
0 N/A
*
[-200 - 200
N/A]
View the two-byte status word (STW) sent to
the bus master. Interpretation of the status
word depends on the serial communication
bus option installed and the control word
profile selected in 8-10 Control Profile.
3.17.7 16-9* Diagnosis Readouts
16-90 Alarm Word
Range: Function:
0 N/A
*
[0 - 4294967295 N/A] View the alarm word sent via the
serial communication port in hex
code.
16-91 Alarm word 2
Range: Function:
0
*
[0 - 4294967295 ] View the alarm word sent via the serial
communication port in hex code.
16-92 Warning Word
Range: Function:
0 N/A
*
[0 - 4294967295 N/A] View the warning word sent via
the serial communication port in
hex code.
16-93 Warning word 2
Range: Function:
0
*
[0 - 4294967295 ] View the warning word sent via the serial
communication port in hex code.
16-94 Ext. Status Word
Range: Function:
0
*
[0 - 4294967295 ] Returns the extended warning word sent
via the serial communication port in hex
code.
16-95 Ext. Status Word 2
Range: Function:
0 N/A
*
[0 - 4294967295 N/A] Returns the extended warning
word 2 sent via the serial
communication port in hex code.
16-96 Maintenance Word
Range: Function:
0 N/A
*
[0 - 4294967295 N/A]
Parameter Descriptions FC 300 Programming Guide
MG.33.MA.22 - VLT
®
is a registered Danfoss trademark 3-137
3
3
