13-51 SL Controller Event
Array [20]
Option: Function:
[70] SL Timeout 3
[71] SL Timeout 4
[72] SL Timeout 5
[73] SL Timeout 6
[74] SL Timeout 7
[75] Start command given
[76] Digital input x30 2
[77] Digital input x30 3
[78] Digital input x30 4
[79] Digital input x46/1
[80] Digital input x46/3
[81] Digital input x46/5
[82] Digital input x46/7
[83] Digital input x46/9
[84] Digital input x46/11
[85] Digital input x46/13
13-52 SL Controller Action
Array [20]
Option: Function:
[0] * DISABLED Select the action corresponding to the SLC
event. Actions are executed when the
corresponding event (defined in 13-51 SL
Controller Event) is evaluated as true. The
following actions are available for selection:
*DISABLED [0]
[1] No action No action [1]
[2] Select set-up 1 Select set-up 1 [2] - changes the active set-up
(par. 0-10) to ‘1’.
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a serial communi-
cation bus.
[3] Select set-up 2 Select set-up 2 [3] - changes the active set-up
(par. 0-10) to ‘2’.
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a serial communi-
cation bus.
[4] Select set-up 3 Select set-up 3 [4] - changes the active set-up
(par. 0-10) to ‘3’.
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a serial communi-
cation bus.
[5] Select set-up 4 Select set-up 4 [5] - changes the active set-up
(par. 0-10) to ‘4’.
13-52 SL Controller Action
Array [20]
Option: Function:
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a serial communi-
cation bus.
[10] Select preset
ref 0
Select preset reference 0 [10] – selects preset
reference 0.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
[11] Select preset
ref 1
Select preset reference 1 [11] – selects preset
reference 1.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
[12] Select preset
ref 2
Select preset reference 2 [12] – selects preset
reference 2.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
[13] Select preset
ref 3
Select preset reference 3 [13] – selects preset
reference 3.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
[14] Select preset
ref 4
Select preset reference 4 [14] – selects preset
reference 4.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
[15] Select preset
ref 5
Select preset reference 5 [15] – selects preset
reference 5.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
[16] Select preset
ref 6
Select preset reference 6 [16] – selects preset
reference 6.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
[17] Select preset
ref 7
Select preset reference 7 [17] - selects preset
reference 7.
Parameter Descriptions FC 300 Programming Guide
MG.33.MA.22 - VLT
®
is a registered Danfoss trademark 3-117
3
3
