13-52 SL Controller Action
Array [20]
Option: Function:
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
[18] Select ramp 1 Select ramp 1 [18] - selects ramp 1.
[19] Select ramp 2 Select ramp 2 [19] - selects ramp 2.
[20] Select ramp 3 Select ramp 3 [20] - selects ramp 3.
[21] Select ramp 4 Select ramp 4 [21] - selects ramp 4.
[22] Run Run [22] - issues a start command to the
adjustable frequency drive.
[23] Run reverse Run reverse [23] - issues a start reverse
command to the adjustable frequency drive.
[24] Stop Stop [24] - issues a stop command to the
adjustable frequency drive.
[25] Q stop Qstop [25] - issues a quick stop command to
the adjustable frequency drive.
[26] Dcstop Dcstop [26] - issues a DC stop command to
the adjustable frequency drive.
[27] Coast Coast [27] - the adjustable frequency drive
coasts immediately. All stop commands
including the coast command stop the SLC.
[28] Freeze output Freeze output [28] - freezes the output
frequency of the adjustable frequency drive.
[29] Start timer 0 Start timer 0 [29] - starts timer 0, see par.
13-20 for further description.
[30] Start timer 1 Start timer 1 [30] - starts timer 1, see par.
13-20 for further description.
[31] Start timer 2 Start timer 2 [31] - starts timer 2, see par.
13-20 for further description.
[32] Set digital out
A low
Set digital output A low [32] - any output with
SL output A will be low.
[33] Set digital out
B low
Set digital output B low [33] - any output with
SL output B will be low.
[34] Set digital out
C low
Set digital output C low [34] - any output with
SL output C will be low.
[35] Set digital out
D low
Set digital output D low [35] - any output with
SL output D will be low.
[36] Set digital out
E low
Set digital output E low [36] - any output with
SL output E will be low.
[37] Set digital out
F low
Set digital output F low [37] - any output with
SL output F will be low.
13-52 SL Controller Action
Array [20]
Option: Function:
[38] Set digital out
A high
Set digital output A high [38] - any output
with SL output A will be high.
[39] Set digital out
B high
Set digital output B high [39] - any output
with SL output B will be high.
[40] Set digital out
C high
Set digital output C high [40] - any output
with SL output C will be high.
[41] Set digital out
D high
Set digital output D high [41] - any output
with SL output D will be high.
[42] Set digital out
E high
Set digital output E high [42] - any output
with SL output E will be high.
[43] Set digital out
F high
Set digital output F high [43] - any output
with SL output F will be high.
[60] Reset Counter
A
Reset Counter A [60] - resets Counter A to
zero.
[61] Reset Counter
B
Reset Counter B [61] - resets Counter B to
zero.
[70] Start timer 3 Start Timer 3 [70] - Start Timer 3, see par.
13-20 for further description.
[71] Start timer 4 Start Timer 4 [71] - Start Timer 4, see par.
13-20 for further description.
[72] Start timer 5 Start Timer 5 [72] - Start Timer 5, see par.
13-20 for further description.
[73] Start timer 6 Start Timer 6 [73] - Start Timer 6, see par.
13-20 for further description.
[74] Start timer 7 Start Timer 7 [74] - Start Timer 7, see par.
13-20 for further description.
Parameter Descriptions FC 300 Programming Guide
3-118 MG.33.MA.22 - VLT
®
