3.3.3 1-2* Motor Data
Parameter group 1-2* comprises input data from the
nameplate on the connected motor.
NOTE!
Changing the value of these parameters affects the setting of
other parameters.
1-20 Motor Power [kW]
Range: Function:
Application
dependent
*
[Application
dependant]
Enter the nominal motor power in
kW according to the motor
nameplate data. The default value
corresponds to the nominal rated
output of the unit.
This parameter cannot be adjusted
while the motor is running. This
parameter is visible in LCP if
0-03 Regional Settings is Interna-
tional [0].
NOTE!
Four sizes down, one size up
from nominal unit rating.
1-21 Motor Power [HP]
Range: Function:
Application
dependent
*
[Application
dependant]
Enter the nominal motor power
in HP according to the motor
nameplate data. The default
value corresponds to the nominal
rated output of the unit. This
parameter is visible in LCP if
0-03 Regional Settings is US [1]
1-22 Motor Voltage
Range: Function:
Application
dependent
*
[Application
dependant]
Enter the nominal motor
voltage according to the motor
nameplate data. The default
value corresponds to the
nominal rated output of the
unit.
1-23 Motor Frequency
Range: Function:
Application
dependent
*
[20 -
1000
Hz]
Min - Max motor frequency: 20–1000 Hz.
Select the motor frequency value from the
motor nameplate data. If a value different
from 50 Hz or 60 Hz is selected, it is
necessary to adapt the load independent
settings in 1-50 Motor Magnetization at
Zero Speed to 1-53 Model Shift Frequency.
For 87 Hz operation with 230/400 V
motors, set the nameplate data for 230 V/
50 Hz. Adapt 4-13 Motor Speed High Limit
[RPM] and 3-03 Maximum Reference to the
87 Hz application.
1-24 Motor Current
Range: Function:
Application
dependent
*
[Application
dependant]
Enter the nominal motor
current value from the motor
nameplate data. The data are
used for calculating torque,
motor protection, etc.
1-25 Motor Nominal Speed
Range: Function:
Application
dependent
*
[10 - 60000
RPM]
Enter the nominal motor speed
value from the motor nameplate
data. The data are used for
calculating motor compensations.
NOTE!
Motor speed must always be
lower than synchronous speed.
1-26 Motor Cont. Rated Torque
Range: Function:
Application
dependent
*
[0.1 -
10000.0
Nm]
Enter the value from the motor
nameplate data. The default value
corresponds to the nominal rated
output. This parameter is available
when 1-10 Motor Construction is set
to PM, non salient SPM [1], i.e., the
parameter is valid for PM and non-
salient SPM motors only.
Parameter Descriptions FC 300 Programming Guide
3-14 MG.33.MA.22 - VLT
®
is a registered Danfoss trademark
3
3
