6-60 Terminal X30/8 Output
Option: Function:
[141] Bus ctrl
0-20mA t.o.
4-54 Warning Reference Low defines the
behavior of the analog output in case of bus
timeout.
[142] Bus ctrl
4-20mA t.o.
4-54 Warning Reference Low defines the
behavior of the analog output in case of bus
timeout.
[149] Torq % lim
4-20 mA
Torque % Lim 4–20 mA: Torque reference.
3-00 Reference Range [Min-Max] 0% = 4 mA;
100% = 20 mA
3-00 Reference Range [-Max - Max] -100% = 4
mA; 0% = 12 mA; +100% = 20 mA
[150] Mx out fr
4-20 mA
In relation to 4-19 Max Output Frequency.
6-61 Terminal X30/8 Min. Scale
Range: Function:
0.00
%
*
[0.00 -
200.00 %]
Scales the minimum output of the selected
analog signal on terminal X30/8. Scale the
minimum value as a percentage of the
maximum signal value, i.e., 0 mA (or 0 Hz) is
desired at 25% of the maximum output value
and 25% is programmed. The value can never
be higher than the corresponding setting in
6-62 Terminal X30/8 Max. Scale if value is below
100%.
This parameter is active when option module
MCB 101 is mounted in the adjustable
frequency drive.
6-62 Terminal X30/8 Max. Scale
Range: Function:
100.00
%
*
[0.00 -
200.00 %]
Scales the maximum output of the selected
analog signal on terminal X30/8. Scale the
value to the desired maximum value of the
current signal output. Scale the output to
give a lower current than 20 mA at full scale
or 20 mA at an output below 100% of the
maximum signal value. If 20 mA is the desired
output current at a value between 0%–100%
of the full-scale output, program the
percentage value in the parameter, i.e., 50% =
20 mA. If a current between 4 and 20 mA is
desired at maximum output (100%), calculate
the percentage value as follows:
20 mA / desired maximum current x 100 %
i . e . 10 mA :
20 − 4
10
x 100 = 160 %
6-63 Terminal X30/8 Bus Control
Range: Function:
0.00 % * [0.00 - 100.00 %] Holds the level of Output X30/8 if
controlled by bus.
6-64 Terminal X30/8 Output Timeout Preset
Range: Function:
0.00 % * [0.00 - 100.00
%]
Holds the preset level of Output X30/8.
In case of a bus timeout and a timeout
function is selected in 6-60 Terminal
X30/8 Output, the output will preset to
this level.
3.8.8 6-7* Analog Output 3 MCB 113
Parameters for configuring the scaling and limits for analog
output 3, Terminal X45/1 and X45/2. Analog outputs are
current outputs: 0/4 – 20 mA. Resolution on analog output is
11 bit.
6-70 Terminal X45/1 Output
Option: Function:
Select the function of Terminal X45/1 as an
analog current output.
[0] No
operation
When no signal on the analog output.
[52] MCO 305
0-20 mA
[53] MCO 305
4-20 mA
[100] Output
frequency 0–
20 mA
0 Hz = 0 mA; 100 Hz = 20 mA.
[101] Reference 0–
20 mA
Par. 3-00 [Min - Max] 0% = 0 mA; 100% = 20
mA
Par. 3-00 [-Max - Max] -100% = 0 mA; 0% = 10
mA; +100% = 20 mA
[102] Feedback
[103] Motor
current 0–20
mA
Value is taken from 16-37 Inv. Max. Current.
Inverter max. current (160% current) is equal
to 20 mA.
Example: Inverter norm current (15 hp [11
kW]) = 24 A. 160% = 38.4 A. Motor norm
current = 22 A Readout 11.46 mA.
20 mA x 22 A
38.4 A
=11.46 mA
If the norm motor current is equal to 20 mA,
the output setting of 6-52 Terminal 42 Output
Max Scale is:
I
VLT
Max
x 100
I
Motor
Norm
=
38.4 x 100
22
=175%
[104] Torque rel to
lim 0–20 mA
The torque setting is related to setting in
4-16 Torque Limit Motor Mode
Parameter Descriptions FC 300 Programming Guide
3-72 MG.33.MA.22 - VLT
®
is a registered Danfoss trademark
3
