FCM 300 Series
MG.03.B6.2G - VLT is a registered Danfoss trademark
Read-out state 2:
Press the [DISPLAY/STATUS] key once to activate
read-out state 2. To return to state 1, push the
[DISPLAY/STATUS] key again.
In this state, four operating values are shown at the
same time. In the example, Reference, Torque,
Current and Frequency are selected as variables in
the first and second line.
Read-out state 3:
Continuously hold down the [DISPLAY/STATUS] key
to activate read-out state 3. Releasing the
[DISPLAY/STATUS] key switches the read-out to
state 2. Push the [DISPLAY/STATUS] key once
more to return to state 1.
This state shows the names of the operating
variables that correspond to the values seen in state
2.
Quick Menu Mode vs. Menu Mode
The FCM 300 has many parameters to
accommodate different applications. The Quick
Menu contains the 10 most utilized parameters that
are needed for programming in most applications. If
the parameters in the Quick Menu do not give the
desired functionality, use of the full Menu is always
available.
NOTE:
Some parameters can be utilized in the Menu
mode. For instance, if Open Loop is chosen in
parameter 100, the PID parameters will be hidden.
MOTOR IS RUNNING
60.0 HZ
24.3% 30.2% 13.8A
60.0 HZ
SETUP
1
MOTOR IS RUNNING
REF% TORQUE CURR A
60.0 HZ
SETUP
1
QUICK MENU X OF Y
001 LANGUAGE
ENGLISH
The parameter names and corresponding numbers
(EX Parameter 001 = Language, Parameter 200 =
Direction of rotation) are the same in Quick Setup
Menu and Menu modes.
Changing a parmeter in one mode automatically
changes the same parmeter in the other mode.
Quick Setup via Quick Menu
Initiate the Quick Setup mode by pressing the
[ QUICK MENU] key once, which gives the following
read-out display:
The 3
rd
Line gives the parameter number and name.
The 4
th
Line shows the status/value of the
parameter. After power-up, the Quick Menu will
always start at Position 1 (See "Parameter
Selection" below).
Parameter Selection
Scroll through the Quick Menu parameters by
pressing the [+/-] keys. The parameters and their
positions within the Quick Menu are as follows:
Pos.:No.: Parameter: Unit:
1 001 Language
2 200 Direction of rotation
3 101 Torque characteristic
4 204 Min. reference [Hz]
5 205 Max. reference [Hz]
6 207 Ramp up time [sec.]
7 208 Ramp down time [sec.]
8 002 Local/remote control
9 003 Local reference
10 500 Bus address
■
Operation
■
■
7-8
