Danfoss FCM305 56 User Manual

FCM 300 Series
MG.03.B6.2G - VLT is a registered Danfoss trademark
✭ = General factory setting - also applying to spare part unit,
HH
HH
H = HVAC setting,
II
II
I = Industrial setting, ( ) = parameter
window text. [ ] = value for use in communication via serial communication port
Description of choice:
States in Hex format whether there is a warning on
the FCM 300.
Hex Status messages
01 Ramping
04 Start clockwise/
counterclockwise
08 Slow down
10 Catch-up
8000 Frequency limit
542 Data read-out: Terminal 1, analog input
(ANALOG INPUT 1)
Value:
Unit: mA
Function:
This parameter can be read out via the serial
communication port.
Description of choice:
The value shown indicates the signal value on
terminal 1.
The scaling (parameters 336 and 337) does not
influence the read-out. Min. and max. are
determined by the offset and gain adjustment of the
AD-converter.
This value is updated every 20 ms.
Parameter Group 5: Technical functions
13-8
541 Data read-out: Warning word, 2
(WARN. WORD 2)
Value:
Unit
Function:
This parameter can be read out via the serial
communication port.
543 Data read-out: Terminal 2, analog input
(ANALOG INPUT 2)
Value:
Unit: X.X V
Function:
This parameter can be read out via the serial
communication port.
Description of choice:
The value shown indicates the signal value on
terminal 2.
The scaling (parameters 338 and 339) does not
influence the read-out. Min. and max. are
determined by the offset and gain adjustment of the
AD-converter.
This value is updated every 20 ms.
