FCM 300 Series
MG.03.B6.2G - VLT is a registered Danfoss trademark
■ Danfoss PC software for serial communication
Using serial communication makes it possible to
monitor, program and control one or several units
from a centrally placed computer. All FCM 300
Series have an RS 485 port as standard, which
enables them to communicate e.g. with a PC. A
program entitled VLT
®
Software Dialog is available
for this purpose.
VLT
®
Dialog operates in the familiar Windows
®
for-
mat.
VLT
®
Dialog incorporates three modules on one disk.
The CD includes the Basic, Logging and Template
Modules, as well as operating instructions - all in six
different languages.
Basic Module
TEST RUN
is used for controlling and commissioning
of a FCM 300, including:
- setting of reference value,
- simultaneous display of selected
parameters in graphs,
- option of DDE link, e.g. to a
spreadsheet.
PARAMETER SETUP
is used for setting up and transferring
parameter sets, including:
- setting of FCM 300 parameters,
- parameter sets can be obtained from
and copied to a FCM 300,
- documentation/print-out of the Setup
including diagrams.
BUS ADDRESS SETUP
is used for setting the bus addresses on
individual FCM 300 nocaps. "units" which
are connected to the same bus.
- setting bus addresses
- storing list of units
- reporting list of units
Logging Module:
LOGGING
is used for collecting and displaying historical
or real-time operating data:
- graphical representation of selected
parameters from several FCM 300 units
- collection of log data to file,
- option of DDE link e.g. to a spreadsheet.
MODEM SETUP
is used for setting up the modem.
- sets the FCM 300 modem via the
communication port of the PC.
Template Module:
TEMPLATE SETUP
is used for setting up template files for PARA-
METER SETUP:
- the template file functions as a mask that
limits the number of accessible
parameters when a parameter file is to be
made or edited in PARAMETER SETUP,
- the template file may contain preset
values for the parameters of the FCM 300.
NOTE!
The logging and template module calls for a Basic
module to be installed on the same PC.
Guided Tour:
The Guided Tour offers a demonstration of the VLT
Software Dialog program.
Serial Communication
15-2
