Danfoss FP715Si Installation Guide

Danfoss Heating
3
GB
FP715Si
Electronic 2-Channel Full Programmer for
Heating & Hot Water with Service Interval Timer
Index
1.0 Installation Overview .............................................................................. 4
2.0 Product Specifi cation ..............................................................................4
3.0 Installation
3.1 Wiring .....................................................................................................5
3.2 DIL Switch Settings ...........................................................................6
4.0 Advanced Programming Options .....................................................6
5.0 Copy Functions Explained ....................................................................7
6.0 Service Interval Timer .............................................................................9
7.0 Wiring Conversions .........................................................................10-17

Danfoss FP715Si Specifications

General

Power Supply	230V AC, 50Hz
Temperature Range	5°C to 30°C
Display	LCD
Mounting	Wall-mounted
Contact Current Rating	3(1)A
Number of Channels	1
Accuracy	±0.5°C
Protection Class	IP30
Program	7-day
Switching Differential	0.5°C
Ambient Temperature	0°C to 40°C
