FP715SI
4
GB
Specifi cation 230V model 24V model
Power supply
230 Vac,
±15%,
50/60 Hz
24 Vac,
±15%,
50/60 Hz
Switching action
2 x SPDT internally linked, Type 1B
Unit switch rating 230 Vac, 3(1)A 24 Vac, 3(1)A
Battery back-up 24 hours minimum
Programme resolution ± 1 minute
Dimensions, mm (W, H, D) 135 x 88 x 32
Design standard EN 60730-2-7
Control Pollution Situation Degree 2
Rated Impulse Voltage 2.5 kV
Ball Pressure Test 75°C
• Remove wallplate from unit by unscrewing the two screws on the
bottom edge of the unit.
• From the top left hand corner of the wallplate, there must be
clearances of at least 140 mm to the right, 15mm to the left,
30mm above and 100mm below in order to mount the plug-on
module.
1.0 Installation Overview
2.0 Product Specifi cation
Please Note:
This product should only be installed by a qualifi ed electrician or
competent heating installer and should be in accordance with the
current edition of the IEEE wiring regulations.
3.0 Installation
