Plug Size and Torque Chart
Item B020
Frame size 069/078 147/165 210/250/280
O-ring plug 7/8–14 1-1/16–12 1-5/16–12
Wrench size 3/8 internal hex 9/16 internal hex 5/8 internal hex
Torque 70 N•m [52 lbf•ft] 70 N•m [52 lbf•ft] 150 N•m [110 lbf•ft]
Items for pump frame size H1P 069—280
Item O-ring plug Wrench size Torque
B015 7/16–20 3/16 mm internal hex 12 N•m [9 lbf•ft]
B035 (069/078)
1 1/16–12 9/16 internal hex 70 N•m [52 lbf•ft]
B035 (147/165)
1 5/16–12 5/8 internal hex 150 N•m [110 lbf•ft]
D065 7/16–20 3/16 internal hex 12 N•m [9 lbf•ft]
G250 9/16–18 1/4 internal hex 40 N•m [29.5 lbf•ft]
G300 9/16–18 3/16 internal hex 40 N•m [29.5 lbf•ft]
G302 5/16–24 UNF 1/8 internal hex 5 N•m [4 lbf•ft]
Service Manual
H1P 069—H1P 280 Axial Piston Single Pumps
Torque Chart
66 |
©
Danfoss | January 2021 AX152886482551en-000601
