Danfoss Maneurop NTZ048 Application Guidelines

Application guidelines
7FRCC.PC.002.A4.22
Dimensions
1 cylinder
Oil equalisation
3/8”
PTC crankcase heater
0.98
3.85
Schrader
1/4”
10.4
13.1
Suction rotolock
1”1/4
Discharge rotolock
1”
2.68
3.22
4.29
4.65
35°
33°
2.68
Suc
tion 5.78
Discharge 5.59
6.28
0.67
17°
4.84
1.54
Threaded oil
sight glass
All dimensions in inch
141
ø 8.8
2.68
HM8-40
0.91
0.59
Silent block
IP rating: 55 (with cable gland)
Spade connectors
1/4" AMP-AWE
Earth M4-12
Ø 0.83 in
Knock-out Ø 0.83 in
Terminal box
Rotolock connections size Pipe sizing Rotolock valve
Suction Discharge Suction Discharge Suction Discharge
NTZ048
NTZ068
1”1/4 1” 5/8” 1/2” V09 V06
