Danfoss Maneurop NTZ048 Application Guidelines

Application guidelines
9FRCC.PC.002.A4.22
Dimensions
4 cylinders
Ø 13.9
20.4
4.61
6.10
9.13
3.9
Oil equalisation
3/8"
Mounting hole for
PTC crankcase heater
All dimensions in inch
15°
15°
15°
9.68
8.07
155°
9.68
Suction rotolock
1"3/4
Discharge rotolock
1"1/4
9.2
8.27
4.9
8.23
3.86
3.74
Threaded oil
sight glass
Schrader 1/4 "
1.18
0.75
HM12-50
Silent block
IP rating: 54 (with cable gland)
Terminal box
Rotolock connections size Pipe sizing Rotolock valve
Suction Discharge Suction Discharge Suction Discharge
NTZ215 - NTZ271 1”3/4 1”1/4 1"1/8” 3/4” V02 V04
