Application guidelines
10 FRCC.PC.002.A4.22
Electrical connections and wiring
Voltage application range
Single phase electrical
characteristics
Nominal capacitor values
and relays
* PSC: Permanent Split Capacitor
CSR: Capacitor Start Run
(1) Run capacitors: 440 volts
(2) Start capacitors: 330 Volts
Single phase motor
protection and suggested
wiring diagram
Single phase compressor motors are internally
protected by a temperature / current-sensing
bimetallic protector which senses the main and
start winding current as well as motor winding
temperature. If the motor were to be overloaded
and the protector trips, it might take up to several
hours to reset and restart the compressor.
The standard CSR wiring system provides addi-
tional motor torque at start-up, by the use of a
start capacitor in combination with a run capac-
itor. The start capacitor is only connected during
the starting operation and a potential relay
disconnects it after the start sequence. This sytem
can be used for refrigerant circuits with capillary
tubes or expansion valves.
Motor voltage code Nominal voltage Voltage application range
1 208-230 V / 1 / 60 Hz 187 – 253 V
3 200-230 V / 3 / 60 Hz 180 – 253 V
4
380-400 V / 3 / 50 Hz
460 V / 3 / 60 Hz
340 – 440 V (50 Hz)
414 – 506 V (60Hz)
5 230 V / 1 / 50 Hz 207 – 253 V
9 380 V / 3 / 60 Hz 342 – 418 V
LRA - Locked Rotor
Current (A)
MCC - Maximum
Continuous Current (A)
Winding resistance (Ω)
( ± 7 % at 68° F)
Motor Code 1 5 1 5 1 5
Winding run start run start
NTZ048 43.7 37 13.2 11 1.32 4.16 1.62 3.95
NTZ068 72 53 21 17 0.94 2.01 1.05 3.19
NTZ096 97 31 0.45 1.84
NTZ108 97 33 0.45 1.84
NTZ136 140 41 0.36 1.73
Models
PSC/CSR* CSR only
Run capacitors (1) Start capacitors (2)
Start
relay
(A) µF (C) µF (B) µF
50 Hz
NTZ048 20 10 100
RVA6AMKL
NTZ068 20 10 100
60 Hz
NTZ048 15 10 100
NTZ068 25 25 135
NTZ096 30 15 135
NTZ108 30 15 135
NTZ136 30 15 135
