Application guidelines
8 FRCC.PC.002.A4.22
Dimensions
2 cylinders
3.85
(1)
4.61 (2)
2.37
6.13
8
Suction 7.03
Discharge 6.93
9.91
ø 11.3
16.3
1.28
Threaded oil
sight glass
All dimensions in inch
Schrader
1/4"
PTC
crankcase heater
3.77
0.81
5.71
4.91
7.41
6.73
8
38
3.22 (1)
3.86 (2)
2.9
2.67
10.43
Suction rotolock
1"3/4
Discharge rotolock
1"1/4
Oil equalisation
3/8"
(1) NTZ096 - 108 - 136 except NTZ136-1
(2) NTZ136-1
HM8-40
0.91
0.59
Silent block
IP rating: 55 (with cable gland)
Spade connectors
1/4" AMP-AWE
Earth M4-12
Ø 0.83 in
Knock-out Ø 0.83 in
Terminal box
(1)
IP rating: 54 (with cable gland)
Terminal box
(2)
Rotolock connections size Pipe sizing Rotolock valve
Suction Discharge Suction Discharge Suction Discharge
NTZ096 - NTZ108 1”3/4 1”1/4 7/8” 3/4” V07 V04
NTZ136 1”3/4 1”1/4 1"1/8” 3/4” V02 V04
