PVG 32 installation of lever
The lever must be screwed in completely.
8 ±1 N•m
3 (1±0.15N•m)
19
.5
°
19
.
5°
PVG Bleeding
If the group is installed vertically, it is recommended to bleed it at the adjusting screws (Pos. A).
It may be necessary to bleed the PVEK because of the hydraulic build-up of PVEA.
PVG 16/32 bleeding
A
Service and Parts Manual
PVG 16/32/128/256
Installation
©
Danfoss | October 2018 AX284661889190en-000101 | 29
