45
FRCC.PC.007.B8.02
Application guidelines
Ordering information and packaging
Single pack
Danfoss SH scroll compressors can be ordered in
either industrial packs or in single packs. Please
use the code numbers from below tables for
ordering.
Compressors SH180 to 485 with rigid mounting
spacers are de
dicated for parallel mounting. For
use in single applications the rigid spacers must
be replaced by exible grommets which are
available as accessory kit 8156138, see section
Accessories.
Ordering information
Compressor
model
Connections
Mounting
feet
Motor
protection
Code no.
34679
200-230/3/60
460/3/60
380-400/3/50
230/3/50
575/3/60
500/3/50
380/3/60
SH090 Brazed exible Internal 120H0001 120H0003 120H0005 120H0007 120H0009
SH105 Brazed exible Internal 120H0209 120H0211 120H0213 120H0215 120H0217
SH120 Brazed exible Internal 120H0011 120H0013 120H0015 120H0017 120H0019
SH140 Brazed exible Internal 120H0199 120H0201 120H0203 120H0205 120H0207
SH161 Brazed exible Internal 120H0021 120H0023 120H0025 120H0027 120H0029
SH184Brazed exible Internal 120H0359 120H0361 120H0363 120H0365 120H0367
SH180
Brazed rigid Module 24V AC * 120H0265 120H0267 - 120H0269 120H0271
Brazed rigid Module 230V * 120H0273 120H0275 - 120H0277 120H0279
SH240
Brazed rigid Module 24V AC * 120H0289 120H0291 - 120H0293 120H0295
Brazed rigid Module 115-230V * 120H0297 120H0299 - 120H0301 120H0303
SH295
Brazed rigid Module 24V AC* 120H0851 120H0825 - 120H0833 120H0841
Brazed rigid Module 115-230V* 120H0853 120H0827 - 120H0835 120H0843
SH300
Brazed rigid Module 24V AC * 120H0233 120H0237 - 120H0241 120H0245
Brazed rigid Module 115-230V * 120H0235 120H0239 - 120H0243 120H0247
SH380
Brazed rigid Mo
dule 24V AC * - 120H0253 - 120H0257 120H0261
Brazed rigid Module 115-230V *
- 120H0255 - 120H0259 120H0263
SH485
Brazed rigid Module 24V AC * - 120H1062 - - 120H1072
Brazed rigid Module 115-230V *
- 120H1064 - - 120H1074
* Electronic motor protectio n, mo dule located in ter m i n a l box
