Danfoss SH090 Application Guidelines

7
FRCC.PC.007.B8.02
Application guidelines
50-60 Hz data
Technical specifications
Model
Nominal tons
60 Hz
Nominal cooling
capacity
Power
input
COP E.E.R. Swept volume
Displacement

Oil charge
Net weight 
TR W Btu/h kW W/W Btu/h/W cm3/rev m3/h dm3 kg
50 Hz
SH090 7.5 22 300 76 100 7.19 3.10 10.59 88.40 15.40 3.0 58.0
SH105 9 26 850 91 600 8.47 3.17 10.80 103.50 18.00 3.3 64.0
SH120 10 30 000 102 200 9.46 3.17 10.80 116.90 20.30 3.3 64.0
SH140 12 34 700 118 400 10.86 3.19 10.90 133.00 23.12 3.3 67.0
SH161 13 38 800 132 400 12.15 3.19 10.90 151.70 26.40 3.3 69.0
SH184 15 44 650 152 500 13.73 3.25 11.10 170.30 29.60 3.6 71.5
SH180 15 44 500 151 800 13.73 3.21 10.95 170.20 29.60 6.7 108.0
SH240 20 60 400 206 300 18.77 3.22 11.00 227.60 39.60 6.7 108.0
SH295 25 73 200 249 800 22.50 3.25 11.10 276.2 48.10 6.7 111.0
SH300 25 75 200 256 400 23.32 3.22 11.00 285.50 49.70 6.7 153.0
SH380 30 90 400 308 700 28.19 3.21 10.95 345.00 60.00 7.2 159.0
SH485 40 116 300 396 900 35.75 3.25 11.10 442.60 77.00 6.7 175.0
60 Hz
SH090 7.5 27 100 92 500 8.57 3.16 10.79 88.40 18.60 3.0 58.0
SH105 9 32 100 109 500 9.96 3.22 11.00 103.50 21.80 3.3 64.0
SH120 10 36 800 125 400 11.25 3.27 11.15 116.90 24.60 3.3 64.0
SH140 12 42 300 144 300 12.94 3.27 11.15 133.00 27.90 3.3 67.0
SH161 13 47 200 160 900 14.43 3.27 11.15 151.70 31.90 3.3 69.0
SH184 15 54 000 184 400 16.45 3.28 11.20 170.30 35.80 3.6 71.5
SH180 15 54 300 185 300 16.45 3.27 11.15 170.20 35.70 6.7 108.0
SH240 20 73 500 251 000 22.48 3.27 11.15 227.60 47.80 6.7 108.0
SH295 25 88 500 302 000 27.20 3.25 11.10 276.20 58.00 6.7 111.0
SH300 25 91 300 311 500 28.19 3.24 11.05 285.50 60.00 6.7 153.0
SH380 30 109 600 374 300 34.02 3.22 11.00 345.00 72.30 7.2 159.0
SH485 40 140 600 479 600 43.28 3.25 11.10 442.60 92.90 6.7 175.0
 Displacement at nominal speed: 2900 rpm at 50 Hz, 3500 rpm at 60 Hz
 Net weight with oil charge
TR: Ton of Refrigeration, Standard rating conditions: ARI standard Evaporating temperature: 7.2 °C Superheat: 11.1 K
EER: Energy E ciency Ratio Refrigerant: R410A Condensing temperature: 54.4 °C Subcooling: 8.3 K
COP: Coe cient Of Performance,
Subject to modi cation without prior noti cation.
For full data details and capacity tables refer to Online Datasheet Generator: www.danfoss.com/odsg
