Application guidelines
Danfoss SH scroll compressors for R410A are
available as single compressors. The example
below presents the compressor nomenclature
which equals the technical reference as shown on
the compressor nameplate.
Code numbers for ordering are listed section
"Ordering information and packaging".
For tandem and trio assemblies, please refer
to the Danfoss SH scroll compressor Parallel
Application Guidelines, FRCC.EC.008.
Nomenclature
Compressor model designation
* for SH485 only. For further information refer to application guidelines FRCC.PC.027.
Family, lubricant
& refrigerant
SH: Scroll, POE lubricant,
for R410A
Motor protection
L: Internal overload protector
A: Electronic, 24V AC
B: Electronic, SH180: 230V
SH240-300-380-485: 115/230V
C: Customized electrical box
J: Operating control system 24V AC*
K: Operating control system 230V AC*
Suction and discharge connections
A: Brazed connections
Family,
lubricant
& refrigerant
Nominal
capacity
Approvals Voltage Version Evolution
index
Evolution index
A~Z
A4SHAAB485
Motor voltage code
3: 200-230V/3~/60 Hz
4: 380-400V/3~/50 Hz - 460V/3~/60 Hz
for SH295 & SH485: 380-415V/3~/50Hz - 460V/3~/60Hz
6: 230V/3~/50 Hz
7: 500V/3~/50 Hz - 575V/3~/60 Hz
9: 380V/3~/60 Hz
UL index
Nominal capacity
in thousand Btu/h at 60 Hz, R410A,
ARI conditions
