Physical Data
Figure 16-2 - Service Side View All Models
484.3 7
Figure 16-3 - Discharge Side View
Discharge Port 229.7 (9.04”) (TT300)
220.2 (8.67”) (TT350, TT400, TT500)
O-RING GROOVE
OD: 88.9 (3.499)
WIDTH: 4.1 (0.1614)
ID: 80.7 (3.177)
O-RING GROOVE
OD: 33.3 (1.311) (TT300 & TG230)
41.3 (1.659) (TT350, TT400, TT500, TT700,
WIDTH: 4.1 (0.1614)
ID: 25.1 (0.988) (TT300 & TG230)
33.1 (1.30) (TT350, TT400, TT500, TT700,
TG310, TG390, TG520)
150 (5.91)
(TT350, TT400, TT500, TG310)
174.0 (6.57 (TT300)
)34.11( 4.092
)34.3( 3.78
787.6 (31.00)
TG310, TG390, TG520)
