mand when each of the following is selected: Digital
input [0], Serial port [1], Logic and [2] or Logic or [3].
Digital input [0]
Dig. input
Ser. port Function
0 0 Stop
0 1 Stop
1 0 Start
1 1 Start
Serial port [1]
Dig. input
Ser. port Function
0 0 Stop
0 1 Start
1 0 Stop
1 1 Start
Logic and [2]
Dig. input
Ser. port Function
0 0 Stop
0 1 Stop
1 0 Stop
1 1 Start
Logic or [3]
Dig. input
Ser. port Function
0 0 Stop
0 1 Start
1 0 Start
1 1 Start
506 Reversing
(REVERSING SELECT)
Value:
Digital input (DIGITAL INPUT) [0]
Serial port (SERIAL PORT) [1]
Logic and (LOGIC AND) [2]
Logic or (LOGIC OR) [3]
Function:
See function description for parameter 502 Coasting
stop.
Description of choice:
The table below shows when the motor is running
clockwise and anti-clockwise when each of the follow-
ing is selected: Digital input [0], Serial port [1], Logic
and [2] or Logic or [3].
Digital input [0]
Dig. input
Ser. port Function
0 0 Clockwise
0 1 Clockwise
1 0 Anti-clockwise
1 1 Anti-clockwise
Serial port [1]
Dig. input
Ser. port Function
0 0 Clockwise
0 1 Anti-clockwise
1 0 Clockwise
1 1 Anti-clockwise
Logic and [2]
Dig. input
Ser. port Function
0 0 Clockwise
0 1 Clockwise
1 0 Clockwise
1 1 Anti-clockwise
Logic or [3]
Dig. input
Ser. port Function
0 0 Clockwise
0 1 Anti-clockwise
1 0 Anti-clockwise
1 1 Anti-clockwise
507 Selection of Setup
(SETUP SELECT)
Value:
Digital input (DIGITAL INPUT) [0]
Serial communication (SERIAL PORT) [1]
Logic and (LOGIC AND) [2]
Logic or (LOGIC OR) [3]
Function:
See function description of parameter 502 Coasting
stop.
Description of choice:
The table below shows which Setup (parameter 004
Active Setup) is selected for each of the following: Dig-
ital input [0], Serial communication [1], Logic and [2]
or Logic or [3].
Digital input [0]
Setup msb
Setup lsb Function
0 0 Setup 1
0 1 Setup 2
1 0 Setup 3
1 1 Setup 4
Serial communication [1]
Setup msb
Setup lsb Function
0 0 Setup 1
0 1 Setup 2
1 0 Setup 3
1 1 Setup 4
= factory setting, () = display text, [] = value for use in communication via serial communication port
124 MG.27.E2.02 - VLT is a registered Danfoss trademark
