Danfoss VLT AHF 005 Service Guide

Block Diagram Name
Spare Part Number
Spare part name Comments 525–690 VAC (T7)
E1h/E3h E2h/E4h FC 102 N450 N500 N560 N630 N710 N800 FC 103 N450 N500 N560 N630 N710 N800 FC 202 N450 N500 N560 N630 N710 N800 FC 302 N355 N400 N500 N560 N630 N710
Control Cards PCA1 130B1151 Control Card, FC102 coated, no safe stop 102 102 102 102 102 102 PCA1 134B1730 Control Card, FC102 coated, no safe stop, Ver 2 card 102 102 102 102 102 102
PCA1 130B1150 Control Card, FC102 coated, safe stop 102 102 102 102 102 102
PCA1 134B1729 Control Card, FC102 coated, safe stop, Ver 2 card 102 102 102 102 102 102
PCA1 130B6968 Control Card, FC103 coated, no safe stop 103 103 103 103 103 103
PCA1 134B1724 Control Card, FC103 coated, no safe stop, Ver 2 card 103 103 103 103 103 103
PCA1 130B6967 Control Card, FC103 coated, safe stop 103 103 103 103 103 103
PCA1 134B1714 Control Card, FC103 coated, safe stop, Ver 2 card 103 103 103 103 103 103
PCA1 130B1168 Control Card, FC202 coated, no safe stop 202 202 202 202 202 202
PCA1 134B1732 Control Card, FC202 coated, no safe stop, Ver 2 card 202 202 202 202 202 202
PCA1 130B1167 Control Card, FC202 coated, safe stop 202 202 202 202 202 202
PCA1 134B1731 Control Card, FC202 coated, safe stop, Ver 2 card 202 202 202 202 202 202
PCA1 130B1109 Control Card, FC302 coated, safe stop 302 302 302 302 302 302
PCA1 134B1726 Control Card, FC302 coated, safe stop, Ver 2 card 302 302 302 302 302 302
Printed Circuit Cards
PCA2 176F6625 Power card high power S/W preloaded, all power sizes, conformal coated, no
scaling card
1 1 1 1 1 1
PCA3 176F3413 Current scaling card 4.02 ohm Installs on the power card 1 – – – – –
PCA3 176F3154 Current scaling card 3.82 ohm Installs on the power card – 1 – – – – PCA3 176F3155 Current scaling card 3.11 ohm Installs on the power card – – 1 – – – PCA3 176F3415 Current scaling card 2.67 ohm Installs on the power card – – – 1 – – PCA3 176F6628 Current scaling card 2.45 ohm Installs on the power card – – – – 1 – PCA3 176F6632 Current scaling card 2.13 ohm Installs on the power card – – – – – 1 PCA4 176F6624 Inrush card 690V Mounts on the SCR/diode modules 1 1 1 1 1 1 PCA5 176F6622 Gatedrive card 690V Gatedrive card includes brake 1 1 1 1 1 1
PCA7 176F3419 Balance/HF card NO 75-800kW 690V Combined high frequency and balance card 1 1 1 1 1 1
PCA16 176F6638 Fan power card high power Fan power card for E-sizes drives 1 1 1 1 1 1
Semiconductors
IGBT1,2,3,4,5,6 176F6643 IGBT module 600A 1700V T7 IGBT module, 1 per kit 6 6 6 6 – –
IGBT1,2,3,4,5,6 176F6644 IGBT module 650A 1700V T7 IGBT module, 1 per kit – – – – 6 6
Spare Parts Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 351
15 15
