Danfoss VLT AHF 005 Service Guide

Block Diagram Name
Spare Part Number
Spare part name Comments 525–690 VAC (T7)
E1h/E3h E2h/E4h FC 102 N450 N500 N560 N630 N710 N800 FC 103 N450 N500 N560 N630 N710 N800 FC 202 N450 N500 N560 N630 N710 N800 FC 302 N355 N400 N500 N560 N630 N710
IGBT7,8 176F6645 IGBT module 450A 1700V E1,E3 brake IGBT module, 1 per kit 2 2 2 2 – – IGBT7,8 176F6646 IGBT module 450A 1700V E2, E4 brake Brake IGBT module, 1 per kit – – – – 2 2
SCR1,2,3 176F6648 Rectier SCR 650A 2200V T7 SCR, 1 per kit 3 3 3 3 3 3 Capacitors CBANK1 176F6635 Capacitor T7 Individual DC bus capacitor, 1 per kit 15 15 18 18 21 21 C1,2,3,4,5,6 176F8534 IGBT snubber cap 1uF 1250V IGBT snubber cap, mounts on IGBT modules 6 6 6 6 – –
C1,2,3,4,5,6 176F3427 IGBT snubber cap 1uF 1250V wide mount IGBT snubber cap, mounts on IGBT modules – – – – 6 6 Fans F2 176F6637 Fan, heat sink, UL 12 P4001 Fan, heat sink, high speed, 172x51mm, 48VDC 3 3 3 3 3 3
F1 176F3167 Top fan IP20 DC 80x38 Fan, IP20, door, 80x38mm, 48VDC 2 2 2 2 2 2
F4 176F6636 Fan, top/door P4001 E1h–E4h Door fan, E1h–E4h, 120x38mm, 48VDC 2 2 2 2 2 2
Fuses FU1,2,3 176F6640 Fuse, T7 P4001 Fuse, size 4, 1250a,700v,170m series 3 3 3 3 3 3
Inductors and Current Sensors CT1,2,3 176F6633 Current sensor 1000A LEM LF1010-S-SPA1, 1 per kit 3 3 3 3 3 3 L1 176F6733 DC link coil 65uH DC inductor 1 1 – – – – L1 176F6734 DC link coil 50uH DC inductor – – 1 1 – –
L1 176F6732 DC link coil 28uH DC inductor – – – – 1 1 Disconnects SW1 176F6315 Switch, disc, 800A, 690V Main disconnect 1 1 1 1 – –
SW1 176F6735 Switch, disc, 1200A, 690V Main disconnect – – – – 1 1
SW1 176F9189 Double disc, handle & rod E frm LHD/AAF Double disc handle & 12x165 mm shaft 1 1 1 1 1 1
Cables CBL1 176F3181 Cable LCP to control card D1h D3h DB9 extension cable assembly 1 1 1 1 1 1 CBL2 176F3183 Cable control card to power card D1H D3H Cable, control card to power card 1 1 1 1 1 1
CBL3 176F6651 Assy, wire, CBL3, P4001, pwr-mixing, E1h Wire harness, power card to mixing fans 1 1 1 1 – –
CBL3 176F6652 Assy, wire, CBL3, P4001, pwr-mixing, E2h Wire harness, power card to mixing fans – – – – 1 1
CBL4 176F6653 Assy, wire, CBL4, P4001, pwr-CT, E1h Wire harness, power card to current sensors 1 1 1 1 – –
CBL4 176F6654 Assy, wire, CBL4, P4001, pwr-CT, E2h Wire harness, power card to current sensors – – – – 1 1
CBL5 176F6693 Assy, wire, CBL5, P4001, DC-pwr, E1h Wire harness, DC bus to fan power supply 1 1 1 1 – – CBL5 176F6694 Assy, wire, CBL5, P4001, DC-pwr, E2h Wire harness, DC bus to fan power supply – – – – 1 1
Spare Parts
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
352 Danfoss A/S © 02/2019 All rights reserved. MG94A502
