Block
Diagram
Name
Spare
Part
Number
Spare part name Comments 525–690 VAC (T7)
E1h/E3h E2h/E4h
FC 102 N450 N500 N560 N630 N710 N800
FC 103 N450 N500 N560 N630 N710 N800
FC 202 N450 N500 N560 N630 N710 N800
FC 302 N355 N400 N500 N560 N630 N710
CBL6 176F3790 Assy, wire, CBL6, P4001, pwr-RFI, E1h Wire harness, power card to HF and RFI
CBL6 176F3791 Assy, wire, CBL6, P4001, pwr-RFI, E2h Wire harness, power card to HF and RFI
CBL7 176F6695 Assy, wire, CBL7, P4001, pwr-GD, E1h Ribbon cable, power card to gatedrive card 1 1 1 1 – –
CBL7 176F6696 Assy, wire, CBL7, P4001, pwr-GD, E2h Ribbon cable, power card to gatedrive card – – – – 1 1
CBL8 176F6697 Assy, wire, CBL8, P4001, pwr-FPC/inrush, E1h Wire harness, inrush card to fan power supply 1 1 1 1 – –
CBL8 176F6698 Assy, wire, CBL8, P4001, pwr-FPC/inrush, E2h Wire harness, inrush card to fan power supply – – – – 1 1
CBL10 176F6699 Assy, wire, CBL10, P4001, inrush-SCR, E1h Wire harness, inrush card to SCR modules 1 1 1 1 – –
CBL10 176F6702 Assy, wire, CBL10, P4001, inrush-SCR, E2h Wire harness, inrush card to SCR modules – – – – 1 1
CBL11 176F6703 Assy, wire, CBL11, P4001, GD-brake, E1h Wire harness, gatedrive to brake IGBT 1 1 1 1 – –
CBL11 176F6704 Assy, wire, CBL11, P4001, GD-brake, E2 Wire harness, gatedrive to brake IGBT – – – – 1 1
CBL12 176F6705 Assy, wire, CBL12, P4001, GD-NTC, E1h Wire harness, gatedrive to IGBT thermal sensor, 1 per kit 3 3 3 3 – –
CBL12 176F6706 Assy, wire, CBL12, P4001, GD-NTC, E2h Wire harness, gatedrive to IGBT thermal sensor, 1 per kit – – – – 3 3
CBL13 176F6707 Assy, wire, CBL13, P4001, GD-IGBT, E1h Wire harness, gatedrive to IGBT module, 1 per kit 3 3 3 3 – –
CBL13 176F6708 Assy, wire, CBL13, P4001, GD-IGBT, E2h Wire harness, gatedrive to IGBT module, 1 per kit – – – – 3 3
CBL14 176F6709 Assy, wire, CBL14, P4001, DC-FPC, E1h Wire harness DC Bus to fan power card 1 1 1 1 1 1
CBL15 176F6655 Assy, wire, CBL15, P4001, FPC-HS, E1h Wire harness, fan power card to heat sink fans 1 1 1 1 – –
CBL15 176F6656 Assy, wire, CBL15, P4001, FPC-HS, E2h Wire harness, fan power card to heat sink fans – – – – 1 1
CBL17 176F6657 Assy, wire, CBL17, P4001, FPC-top, E1hE2h, IP20 Wire harness, fan power card to top fans, IP20 1 1 1 1 1 1
CBL17 176F6658 Assy, wire, CBL17, P4001, FPC-door, E1hE2h, IP54 Wire harness, fan power card to door fans, IP21/IP54 1 1 1 1 1 1
Terminals, Labels, Insulators
TB1 176F6686 Terminal suppt, main, motor, E1h–E4h Mains term insulation block, black plastic 3 3 3 3 3 3
TB2 176F6686 Terminal suppt, main, motor, E1h–E4h Motor term insulation block, black plastic 3 3 3 3 3 3
176F6677 Insul, plas, active inrush, E1h–E4h Bracket inrush support, mounts above SCRs 1 1 1 1 1 1
176F6672 Insul, plas, PC, GD, PCA, support, P4001 Bracket gatedrive support, mounts above IGBTs 1 1 1 1 1 1
Busbars
176F6680 Busbar, SCR AC input, E1h, E3h Mains busbars to SCRs 3 3 3 3 – –
176F6681 Busbar, SCR AC input, E2h,E4h Mains busbars to SCRs – – – – 3 3
176F6663 Busbar, DC link SCR multi, E1hE3h, N315,N355 Connects SCR to DC coil; +/- busbars & Mylar assy 1 1 1 1 – –
176F6662 Busbar, DC link SCR multi, E2h,E4h Connects SCR to DC coil; +/- busbars & Mylar assy – – – – 1 1
176F6675 Busbar, AC input to inrush PCA, E1,E2 Set of 3 small AC busbars to inrush card 1 1 1 1 – –
176F6676 Busbar, AC input to inrush PCA, E2,E3 Set of 3 small AC busbars to inrush card – – – – 1 1
Spare Parts Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 353
